The part looked right on the screen. It cleared internal review. It even passed a quick Design For Manufacturing (DFM) check inside the Computer Aided Design environment. Then it reached the shop floor. The supplier came back with questions. Computer-Aided Manufacturing (CAM) needed adjustments. Inspection could not interpret the datums. The quote was revised. Two weeks disappeared before the first cut.
In 2026, Computer Aided Design models will feed directly into automated quoting, CAM programming, and model-based inspection. When design intent is unclear inside the CAD model, those systems do not adapt. They pause.
This is an outlook on the CAD mistakes already slowing Manufacturing, and why they will matter more moving forward.
Manufacturing workflows have tightened. Suppliers are reducing buffers. Automation is replacing manual interpretation. Model-based processes are moving from pilots to daily operations. Computer Aided Design files are no longer just geometry; they are executable manufacturing inputs.
In this environment, small ambiguities inside Computer Aided Design scale into real delays. Issues that once cost hours now cost days.
Below are ten refined CAD errors that consistently delay Manufacturing, grounded in what suppliers, standards bodies, and real production workflows are already signaling.
The most frequent issue we see is designs that look polished on screen but are impractical for the chosen process. A part modeled without draft for injection molding. A CNC part with unreachable pockets. A 3D-printed geometry that ignores support strategy. Design for Manufacturing and Design for Manufacturability are no longer downstream checks. When they’re ignored, rework and late-stage fixes become inevitable.
Missing dimensions, unclear tolerances, or incomplete Geometric Dimensioning and Tolerancing (GD&T) force manufacturers to guess or stop and ask. Standards like ASME Y14.5 exist precisely to avoid this ambiguity, yet inconsistent application remains common. As inspection planning becomes more automated, unclear annotation increasingly blocks progress rather than slowing it.
We regularly see manufacturers working from outdated files, wrong revisions, or mismatched drawings and models. The result is scrap, wasted material, and lost time. As CAD-to-CAM workflows automate further, disciplined version control becomes a manufacturing requirement, not an internal housekeeping task.
Mixing millimeters and inches, or importing blocks with incorrect scaling, still causes real production issues. These mistakes often surface only after CAM programming or tooling preparation, when correction is most expensive. Unit discipline is basic, but in automated workflows, small setup errors cascade quickly.
Complex features that add no functional benefit increase machining time, tooling complexity, and inspection effort. CNC design guides consistently recommend simplifying geometry and aligning tolerances with capability. Moving forward, suppliers under lead-time pressure will deprioritize unnecessarily complex designs.
Material choice is not just about strength or cost. Shrinkage in plastics, tool wear in hard metals, flow behavior in molding, and anisotropy in additive manufacturing all affect outcomes. Injection molding and machining guidelines document these effects clearly. Designs that ignore material behavior often fail late, when changes are hardest.
When design, engineering, and manufacturing operate in isolation, critical assumptions go unchallenged. We’re seeing that early alignment prevents most downstream delays. CAD that reflects real manufacturing constraints moves faster through production than designs finalized in isolation.
Gaps, overlaps, unconstrained sketches, and non-manifold geometry still disrupt CAM toolpaths and file translations. These issues are common when moving between software systems. Clean geometry is essential as CAD files become executable inputs to manufacturing systems
Teams that ignore standard templates, naming conventions, and industry guidelines create friction at scale. ISO and ASME standards exist to create shared understanding. When each project reinvents structure, manufacturing interpretation slows.
Individual parts may look fine, but without full assembly validation, collisions and fit issues surface only during physical build. CAD assembly checks are cheaper than rework, yet still skipped under schedule pressure. In faster 2026 workflows, these misses will cost more than time saved.
A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.
A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.
A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.
An impact-resistant and transparent material often CNC machined into parts like safety goggles, electronic enclosures, and automotive lighting covers due to its excellent strength and optical clarity.
A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.
A durable and impact-resistant thermoplastic commonly CNC machined into parts like prototypes, enclosures, and consumer goods due to its good mechanical properties, ease of machining, and wide range of available colors.
A metal alloy known for its excellent machinability and corrosion resistance, often CNC machined into parts like fittings, valves, and decorative components due to its aesthetic appeal and durability.
A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.
A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.
A lightweight and versatile material used for CNC machining applications like packaging inserts, architectural models, and signage due to its ease of machining, low density, and impact-absorbing properties.
A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.
A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.
A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.
A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.
An impact-resistant and transparent material often CNC machined into parts like safety goggles, electronic enclosures, and automotive lighting covers due to its excellent strength and optical clarity.
A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.
A durable and impact-resistant thermoplastic commonly CNC machined into parts like prototypes, enclosures, and consumer goods due to its good mechanical properties, ease of machining, and wide range of available colors.
A metal alloy known for its excellent machinability and corrosion resistance, often CNC machined into parts like fittings, valves, and decorative components due to its aesthetic appeal and durability.
A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.
A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.
A lightweight and versatile material used for CNC machining applications like packaging inserts, architectural models, and signage due to its ease of machining, low density, and impact-absorbing properties.
A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.
| Material | Mechanical Properties | Physical Properties | Chemical Properties | Features | Common Applications |
|---|---|---|---|---|---|
|
Tensile Strength: 60-70 MPa Impact Strength: 10-20 kJ/m² Heat Deflection Temperature: 135-150°C |
Transparent or translucent Good dimensional stability |
Resistant to many chemicals and oils
|
Excellent transparency High temperature resistance |
Aerospace and Defense: Transparent canopies, Medical: Medical device components |
|
|
Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Heat Deflection Temperature: 100-120°C |
Various colors available Good dimensional stability |
Resistant to many chemicals and oils
|
Suitable for high-temperature applications |
Aerospace and Defense: Engine components, Automotive: Engine components |
|
|
Tensile Strength: 60-80 MPa Impact Strength: 20-40 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C |
Various colors available Low density Good dimensional stability |
Resistant to many chemicals and oils
|
High strength and impact resistance Lightweight |
Automotive: Bumpers, Aerospace and Defense: Structural components |
|
|
Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C |
Black color Low density Good dimensional stability |
Resistant to many chemicals and oils
|
Black appearance
Lightweight - Durable |
Consumer Products: Electronics casings, automotive interior parts |
|
|
Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C |
White color Low density Good dimensional stability |
Resistant to many chemicals and oils
|
White appearance
Lightweight Durable |
Consumer Products: Electronics casings, toys, kitchen appliances |
|
|
ABS |
Good impact resistance |
Density: 1.03 g/cm³ |
Resistant to diluted acids, alkalis |
High strength, versatility,
cost-effective |
Automotive, Consumer Products |
|
ABS – M30i |
- Good tensile strength |
- Density: 1.04 g/cm³ |
- Medical grade |
- Biocompatible, sterilizable, suitable for medical devices |
Medical |
|
ABS ESD |
- Static-dissipative properties |
- Density: 1.06 g/cm³ |
- ESD protection |
- Prevents electrostatic discharge, suitable for electronics |
Aerospace and Defense, Consumer Products |
|
ABS-Like |
- High toughness and durability |
- Density: Varies by formulation |
- Resistant to various chemicals |
- Resembles ABS but may offer specific improvements |
Varies by formulation |
|
Accura 25 |
- High accuracy and resolution |
- Density: Varies by formulation |
- Photopolymer |
- Used in stereolithography 3D printing, fine details |
Consumer Products, Medical, Aerospace and Defense |
|
Accura 60 |
- High strength and durability |
- Density: Varies by formulation |
- Photopolymer |
- Tough and durable, suitable for functional prototypes |
Consumer Products, Aerospace and Defense |
|
Accura AMX Rigid Black |
- High impact resistance |
- Density: Varies by formulation |
- Photopolymer |
- Rigid and durable, good for functional prototypes |
Consumer Products, Aerospace and Defense |
|
Accura ClearVue |
- High transparency and clarity |
- Density: Varies by formulation |
- Photopolymer |
- Crystal clear appearance, ideal for clear parts |
Consumer Products, Medical |
|
Accura Xtreme Grey/White |
- High toughness and durability |
- Density: Varies by formulation |
- Photopolymer |
- Resistant to high temperatures, strong and rigid |
Consumer Products, Aerospace and Defense |
|
ASA |
- Excellent UV resistance |
- Density: 1.07 g/cm³ |
- Weather-resistant |
- Outdoor durability, retains color and strength in sunlight |
Automotive, Consumer Products |
|
Nylon |
- High tensile strength |
- Density: 1.15 g/cm³ |
- Resistant to moisture, chemicals |
- Tough and durable, suitable for functional parts |
Aerospace and Defense, Automotive, Consumer Products |
|
Nylon 11 Flame Retardant |
- Flame retardant properties |
- Density: Varies by formulation |
- Flame-resistant |
- Fire safety, suitable for applications requiring flame resistance |
Aerospace and Defense, Automotive |
|
Nylon 12 |
- Good chemical resistance |
- Density: 1.02 g/cm³ |
- Resistant to oils, greases |
- Versatile, suitable for various industrial applications |
Aerospace and Defense, Automotive, Consumer Products, Oil and Gas |
|
Nylon 6 |
- High impact strength |
- Density: 1.14 g/cm³ |
- Resistant to moisture, abrasion |
- Durable, excellent for applications requiring impact resistance |
Automotive, Consumer Products |
|
PA 12 Glass Beads |
- Improved stiffness and dimensional stability |
- Density: Varies by formulation |
- Reinforced with glass beads |
- Increased stiffness, suitable for engineering applications |
Automotive, Aerospace and Defense |
|
PC-ISO |
- High strength and heat resistance |
- Density: Varies by formulation |
- Biocompatible |
- Suitable for medical and aerospace applications |
Aerospace and Defense, Medical |
|
PC+ABS |
- Good impact resistance |
- Density: Varies by formulation |
- Resistant to chemicals |
- Blends properties of PC and ABS, versatile material |
Automotive, Consumer Products |
|
PETG |
- Excellent transparency and impact resistance |
- Density: 1.27 g/cm³ |
- Food-safe, BPA-free |
- Clarity and toughness, ideal for packaging and displays |
Consumer Products, Medical |
|
PLA |
- Biodegradable and easy to print |
- Density: 1.24 g/cm³ |
- Biodegradable |
- Eco-friendly, easy to 3D print |
Consumer Products, Medical |
|
Polycarbonate (PC) |
- High impact resistance, optical clarity |
- Density: 1.20 g/cm³ |
- Excellent optical properties |
- Exceptional clarity and strength, suitable for transparent parts |
Aerospace and Defense, Consumer Products, Medical |
|
Polypropylene |
- Low density and good chemical resistance |
- Density: 0.90 g/cm³ |
- Resistant to moisture, chemicals |
- Lightweight, suitable for low-stress applications |
Consumer Products, Automotive |
|
Rubber-Like |
- Flexible and rubber-like properties |
- Density: Varies by formulation |
- Flexible elastomer |
- Mimics rubber, suitable for gaskets and seals |
Automotive, Consumer Products |
|
Somos Evolve |
- High strength and heat resistance |
- Density: Varies by formulation |
- Photopolymer |
- Engineering-grade material, suitable for functional prototypes |
Aerospace and Defense, Automotive |
|
Somos PerFORM |
- High stiffness and heat resistance |
- Density: Varies by formulation |
- Photopolymer |
- Strong and stiff, ideal for high-temperature applications |
Aerospace and Defense |
|
Somos Waterclear |
- High transparency and clarity |
- Density: Varies by formulation |
- Photopolymer |
- Transparent, suitable for clear prototypes and parts |
Consumer Products, Medical |
|
Somos Watershed |
- Excellent clarity and water resistance |
- Density: Varies by formulation |
- Photopolymer |
- Waterproof, suitable for water-resistant parts |
Consumer Products, Medical |
|
ST-130 |
- High toughness and durability |
- Density: Varies by formulation |
- Photopolymer |
- Rigid, tough, and durable, good for functional prototypes |
Consumer Products, Aerospace and Defense |
|
TPU 88A |
- Flexible and elastomeric properties |
- Density: Varies by formulation |
- Thermoplastic polyurethane |
- Flexibility and resilience, suitable for elastomeric parts |
Automotive, Consumer Products, Medical |
|
Ultem 1010 |
- High strength, heat, and chemical resistance |
- Density: 1.27 g/cm³ |
- Flame-resistant, UL 94 V0 |
- Engineering-grade thermoplastic with excellent properties |
Aerospace and Defense, Automotive, Oil and Gas |
|
Ultem 9085 |
- High strength, heat, and chemical resistance |
- Density: 1.27 g/cm³ |
- Flame-resistant, UL 94 V0 |
- Suitable for aerospace and transportation applications |
Aerospace and Defense, Automotive |
|
Vero |
- Rigid and durable |
- Density: Varies by formulation |
- Photopolymer |
- Versatile material, good for prototypes and models |
Consumer Products, Aerospace and Defense |
|
VeroClear |
- High transparency and clarity |
- Density: Varies by formulation |
- Photopolymer |
- Transparent appearance, ideal for clear parts |
Consumer Products, Medical |
What’s different heading into 2026 is not the existence of these mistakes, but the environment around them. Manufacturing is faster, more automated, and less forgiving. CAD files are no longer advisory. They are instructions.
From what we see at PrintForm, teams that treat Computer Aided Design as a manufacturing discipline rather than a design deliverable move faster, face fewer questions, and spend less time correcting avoidable issues.
The delays of 2026 are being designed today. Strong Design for Manufacturing and Design for Manufacturability practices are no longer optional safeguards. They are competitive advantages. Teams that internalize this shift now will not just avoid delays. They’ll set the pace.
A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.
A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.
A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.
An impact-resistant and transparent material often CNC machined into parts like safety goggles, electronic enclosures, and automotive lighting covers due to its excellent strength and optical clarity.
A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.
A durable and impact-resistant thermoplastic commonly CNC machined into parts like prototypes, enclosures, and consumer goods due to its good mechanical properties, ease of machining, and wide range of available colors.
A metal alloy known for its excellent machinability and corrosion resistance, often CNC machined into parts like fittings, valves, and decorative components due to its aesthetic appeal and durability.
A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.
A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.
A lightweight and versatile material used for CNC machining applications like packaging inserts, architectural models, and signage due to its ease of machining, low density, and impact-absorbing properties.
A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.
A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.
A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.
A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.
An impact-resistant and transparent material often CNC machined into parts like safety goggles, electronic enclosures, and automotive lighting covers due to its excellent strength and optical clarity.
A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.
A durable and impact-resistant thermoplastic commonly CNC machined into parts like prototypes, enclosures, and consumer goods due to its good mechanical properties, ease of machining, and wide range of available colors.
A metal alloy known for its excellent machinability and corrosion resistance, often CNC machined into parts like fittings, valves, and decorative components due to its aesthetic appeal and durability.
A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.
A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.
A lightweight and versatile material used for CNC machining applications like packaging inserts, architectural models, and signage due to its ease of machining, low density, and impact-absorbing properties.
A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.
| Material | Mechanical Properties | Physical Properties | Chemical Properties | Features | Common Applications |
|---|---|---|---|---|---|
|
Tensile Strength: 60-70 MPa Impact Strength: 10-20 kJ/m² Heat Deflection Temperature: 135-150°C |
Transparent or translucent Good dimensional stability |
Resistant to many chemicals and oils
|
Excellent transparency High temperature resistance |
Aerospace and Defense: Transparent canopies, Medical: Medical device components |
|
|
Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Heat Deflection Temperature: 100-120°C |
Various colors available Good dimensional stability |
Resistant to many chemicals and oils
|
Suitable for high-temperature applications |
Aerospace and Defense: Engine components, Automotive: Engine components |
|
|
Tensile Strength: 60-80 MPa Impact Strength: 20-40 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C |
Various colors available Low density Good dimensional stability |
Resistant to many chemicals and oils
|
High strength and impact resistance Lightweight |
Automotive: Bumpers, Aerospace and Defense: Structural components |
|
|
Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C |
Black color Low density Good dimensional stability |
Resistant to many chemicals and oils
|
Black appearance
Lightweight - Durable |
Consumer Products: Electronics casings, automotive interior parts |
|
|
Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C |
White color Low density Good dimensional stability |
Resistant to many chemicals and oils
|
White appearance
Lightweight Durable |
Consumer Products: Electronics casings, toys, kitchen appliances |
|
|
ABS |
Good impact resistance |
Density: 1.03 g/cm³ |
Resistant to diluted acids, alkalis |
High strength, versatility,
cost-effective |
Automotive, Consumer Products |
|
ABS – M30i |
- Good tensile strength |
- Density: 1.04 g/cm³ |
- Medical grade |
- Biocompatible, sterilizable, suitable for medical devices |
Medical |
|
ABS ESD |
- Static-dissipative properties |
- Density: 1.06 g/cm³ |
- ESD protection |
- Prevents electrostatic discharge, suitable for electronics |
Aerospace and Defense, Consumer Products |
|
ABS-Like |
- High toughness and durability |
- Density: Varies by formulation |
- Resistant to various chemicals |
- Resembles ABS but may offer specific improvements |
Varies by formulation |
|
Accura 25 |
- High accuracy and resolution |
- Density: Varies by formulation |
- Photopolymer |
- Used in stereolithography 3D printing, fine details |
Consumer Products, Medical, Aerospace and Defense |
|
Accura 60 |
- High strength and durability |
- Density: Varies by formulation |
- Photopolymer |
- Tough and durable, suitable for functional prototypes |
Consumer Products, Aerospace and Defense |
|
Accura AMX Rigid Black |
- High impact resistance |
- Density: Varies by formulation |
- Photopolymer |
- Rigid and durable, good for functional prototypes |
Consumer Products, Aerospace and Defense |
|
Accura ClearVue |
- High transparency and clarity |
- Density: Varies by formulation |
- Photopolymer |
- Crystal clear appearance, ideal for clear parts |
Consumer Products, Medical |
|
Accura Xtreme Grey/White |
- High toughness and durability |
- Density: Varies by formulation |
- Photopolymer |
- Resistant to high temperatures, strong and rigid |
Consumer Products, Aerospace and Defense |
|
ASA |
- Excellent UV resistance |
- Density: 1.07 g/cm³ |
- Weather-resistant |
- Outdoor durability, retains color and strength in sunlight |
Automotive, Consumer Products |
|
Nylon |
- High tensile strength |
- Density: 1.15 g/cm³ |
- Resistant to moisture, chemicals |
- Tough and durable, suitable for functional parts |
Aerospace and Defense, Automotive, Consumer Products |
|
Nylon 11 Flame Retardant |
- Flame retardant properties |
- Density: Varies by formulation |
- Flame-resistant |
- Fire safety, suitable for applications requiring flame resistance |
Aerospace and Defense, Automotive |
|
Nylon 12 |
- Good chemical resistance |
- Density: 1.02 g/cm³ |
- Resistant to oils, greases |
- Versatile, suitable for various industrial applications |
Aerospace and Defense, Automotive, Consumer Products, Oil and Gas |
|
Nylon 6 |
- High impact strength |
- Density: 1.14 g/cm³ |
- Resistant to moisture, abrasion |
- Durable, excellent for applications requiring impact resistance |
Automotive, Consumer Products |
|
PA 12 Glass Beads |
- Improved stiffness and dimensional stability |
- Density: Varies by formulation |
- Reinforced with glass beads |
- Increased stiffness, suitable for engineering applications |
Automotive, Aerospace and Defense |
|
PC-ISO |
- High strength and heat resistance |
- Density: Varies by formulation |
- Biocompatible |
- Suitable for medical and aerospace applications |
Aerospace and Defense, Medical |
|
PC+ABS |
- Good impact resistance |
- Density: Varies by formulation |
- Resistant to chemicals |
- Blends properties of PC and ABS, versatile material |
Automotive, Consumer Products |
|
PETG |
- Excellent transparency and impact resistance |
- Density: 1.27 g/cm³ |
- Food-safe, BPA-free |
- Clarity and toughness, ideal for packaging and displays |
Consumer Products, Medical |
|
PLA |
- Biodegradable and easy to print |
- Density: 1.24 g/cm³ |
- Biodegradable |
- Eco-friendly, easy to 3D print |
Consumer Products, Medical |
|
Polycarbonate (PC) |
- High impact resistance, optical clarity |
- Density: 1.20 g/cm³ |
- Excellent optical properties |
- Exceptional clarity and strength, suitable for transparent parts |
Aerospace and Defense, Consumer Products, Medical |
|
Polypropylene |
- Low density and good chemical resistance |
- Density: 0.90 g/cm³ |
- Resistant to moisture, chemicals |
- Lightweight, suitable for low-stress applications |
Consumer Products, Automotive |
|
Rubber-Like |
- Flexible and rubber-like properties |
- Density: Varies by formulation |
- Flexible elastomer |
- Mimics rubber, suitable for gaskets and seals |
Automotive, Consumer Products |
|
Somos Evolve |
- High strength and heat resistance |
- Density: Varies by formulation |
- Photopolymer |
- Engineering-grade material, suitable for functional prototypes |
Aerospace and Defense, Automotive |
|
Somos PerFORM |
- High stiffness and heat resistance |
- Density: Varies by formulation |
- Photopolymer |
- Strong and stiff, ideal for high-temperature applications |
Aerospace and Defense |
|
Somos Waterclear |
- High transparency and clarity |
- Density: Varies by formulation |
- Photopolymer |
- Transparent, suitable for clear prototypes and parts |
Consumer Products, Medical |
|
Somos Watershed |
- Excellent clarity and water resistance |
- Density: Varies by formulation |
- Photopolymer |
- Waterproof, suitable for water-resistant parts |
Consumer Products, Medical |
|
ST-130 |
- High toughness and durability |
- Density: Varies by formulation |
- Photopolymer |
- Rigid, tough, and durable, good for functional prototypes |
Consumer Products, Aerospace and Defense |
|
TPU 88A |
- Flexible and elastomeric properties |
- Density: Varies by formulation |
- Thermoplastic polyurethane |
- Flexibility and resilience, suitable for elastomeric parts |
Automotive, Consumer Products, Medical |
|
Ultem 1010 |
- High strength, heat, and chemical resistance |
- Density: 1.27 g/cm³ |
- Flame-resistant, UL 94 V0 |
- Engineering-grade thermoplastic with excellent properties |
Aerospace and Defense, Automotive, Oil and Gas |
|
Ultem 9085 |
- High strength, heat, and chemical resistance |
- Density: 1.27 g/cm³ |
- Flame-resistant, UL 94 V0 |
- Suitable for aerospace and transportation applications |
Aerospace and Defense, Automotive |
|
Vero |
- Rigid and durable |
- Density: Varies by formulation |
- Photopolymer |
- Versatile material, good for prototypes and models |
Consumer Products, Aerospace and Defense |
|
VeroClear |
- High transparency and clarity |
- Density: Varies by formulation |
- Photopolymer |
- Transparent appearance, ideal for clear parts |
Consumer Products, Medical |
A medical device startup spent eight months perfecting their prototypes. The design won awards. Investors lined up. Then they scaled to production, and the failure rate hit 40 percent.
When selecting the manufacturing process for functional prototypes or low-volume production, the decision can often feel overwhelming.
The production line was ready. Materials were in. Demand was real. Then a single tool cracked.
The first prototype looked perfect on screen. Clean geometry. Tight tolerances. Everyone nodded in the review.
In early 2020, a mid-sized molding supplier in Eastern Europe found itself in an unforeseen crisis.
In Silicon Valley, a product team racing against time had their prototype ready but something was wrong.
The part looked right on the screen. It cleared internal review. It even passed a quick Design For Manufacturing (DFM) check inside the Computer Aided Design environment.
Rapid Prototyping Is No Longer a Safety Net. It’s the Critical Path.
In the rapidly evolving healthcare and medical product development marketplace...
In the realm of modern manufacturing, CNC machining redefines precision...
The EV industry is evolving rapidly with the help of 3D printing...
Dramatic healthcare needs during COVID-19 created urgent manufacturing demand...
Getting quotes has never been more convenient...
Another successful year for PrintForm driven by customer satisfaction...
Our molding experience has grown tremendously over the years...
SLS technology is suitable for complex designs and applications...
Experience the power of PrintForm’s CNC machining services, where precision meets versatility. Our advanced manufacturing processes and skilled engineering team offer an extensive array of finish and secondary processing options. With a commitment to exceeding your expectations, we prioritize your unique requirements over any specific technology or machine. Whether it’s high-quality plastic or metal components, our CNC machining capabilities deliver unmatched dimensional accuracy, critical surface finishes, and material-specific properties. Trust PrintForm to provide precision engineering solutions that empower your success in today’s competitive landscape.
A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.
A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.
A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.
An impact-resistant and transparent material often CNC machined into parts like safety goggles, electronic enclosures, and automotive lighting covers due to its excellent strength and optical clarity.
A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.
A durable and impact-resistant thermoplastic commonly CNC machined into parts like prototypes, enclosures, and consumer goods due to its good mechanical properties, ease of machining, and wide range of available colors.
A metal alloy known for its excellent machinability and corrosion resistance, often CNC machined into parts like fittings, valves, and decorative components due to its aesthetic appeal and durability.
A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.
A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.
A lightweight and versatile material used for CNC machining applications like packaging inserts, architectural models, and signage due to its ease of machining, low density, and impact-absorbing properties.
A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.
A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.
A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.
A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.
An impact-resistant and transparent material often CNC machined into parts like safety goggles, electronic enclosures, and automotive lighting covers due to its excellent strength and optical clarity.
A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.
A durable and impact-resistant thermoplastic commonly CNC machined into parts like prototypes, enclosures, and consumer goods due to its good mechanical properties, ease of machining, and wide range of available colors.
A metal alloy known for its excellent machinability and corrosion resistance, often CNC machined into parts like fittings, valves, and decorative components due to its aesthetic appeal and durability.
A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.
A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.
A lightweight and versatile material used for CNC machining applications like packaging inserts, architectural models, and signage due to its ease of machining, low density, and impact-absorbing properties.
A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.
| Material | Mechanical Properties | Physical Properties | Chemical Properties | Features | Common Applications |
|---|---|---|---|---|---|
|
Tensile Strength: 60-70 MPa Impact Strength: 10-20 kJ/m² Heat Deflection Temperature: 135-150°C |
Transparent or translucent Good dimensional stability |
Resistant to many chemicals and oils
|
Excellent transparency High temperature resistance |
Aerospace and Defense: Transparent canopies, Medical: Medical device components |
|
|
Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Heat Deflection Temperature: 100-120°C |
Various colors available Good dimensional stability |
Resistant to many chemicals and oils
|
Suitable for high-temperature applications |
Aerospace and Defense: Engine components, Automotive: Engine components |
|
|
Tensile Strength: 60-80 MPa Impact Strength: 20-40 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C |
Various colors available Low density Good dimensional stability |
Resistant to many chemicals and oils
|
High strength and impact resistance Lightweight |
Automotive: Bumpers, Aerospace and Defense: Structural components |
|
|
Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C |
Black color Low density Good dimensional stability |
Resistant to many chemicals and oils
|
Black appearance
Lightweight - Durable |
Consumer Products: Electronics casings, automotive interior parts |
|
|
Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C |
White color Low density Good dimensional stability |
Resistant to many chemicals and oils
|
White appearance
Lightweight Durable |
Consumer Products: Electronics casings, toys, kitchen appliances |
|
|
ABS |
Good impact resistance |
Density: 1.03 g/cm³ |
Resistant to diluted acids, alkalis |
High strength, versatility,
cost-effective |
Automotive, Consumer Products |
|
ABS – M30i |
- Good tensile strength |
- Density: 1.04 g/cm³ |
- Medical grade |
- Biocompatible, sterilizable, suitable for medical devices |
Medical |
|
ABS ESD |
- Static-dissipative properties |
- Density: 1.06 g/cm³ |
- ESD protection |
- Prevents electrostatic discharge, suitable for electronics |
Aerospace and Defense, Consumer Products |
|
ABS-Like |
- High toughness and durability |
- Density: Varies by formulation |
- Resistant to various chemicals |
- Resembles ABS but may offer specific improvements |
Varies by formulation |
|
Accura 25 |
- High accuracy and resolution |
- Density: Varies by formulation |
- Photopolymer |
- Used in stereolithography 3D printing, fine details |
Consumer Products, Medical, Aerospace and Defense |
|
Accura 60 |
- High strength and durability |
- Density: Varies by formulation |
- Photopolymer |
- Tough and durable, suitable for functional prototypes |
Consumer Products, Aerospace and Defense |
|
Accura AMX Rigid Black |
- High impact resistance |
- Density: Varies by formulation |
- Photopolymer |
- Rigid and durable, good for functional prototypes |
Consumer Products, Aerospace and Defense |
|
Accura ClearVue |
- High transparency and clarity |
- Density: Varies by formulation |
- Photopolymer |
- Crystal clear appearance, ideal for clear parts |
Consumer Products, Medical |
|
Accura Xtreme Grey/White |
- High toughness and durability |
- Density: Varies by formulation |
- Photopolymer |
- Resistant to high temperatures, strong and rigid |
Consumer Products, Aerospace and Defense |
|
ASA |
- Excellent UV resistance |
- Density: 1.07 g/cm³ |
- Weather-resistant |
- Outdoor durability, retains color and strength in sunlight |
Automotive, Consumer Products |
|
Nylon |
- High tensile strength |
- Density: 1.15 g/cm³ |
- Resistant to moisture, chemicals |
- Tough and durable, suitable for functional parts |
Aerospace and Defense, Automotive, Consumer Products |
|
Nylon 11 Flame Retardant |
- Flame retardant properties |
- Density: Varies by formulation |
- Flame-resistant |
- Fire safety, suitable for applications requiring flame resistance |
Aerospace and Defense, Automotive |
|
Nylon 12 |
- Good chemical resistance |
- Density: 1.02 g/cm³ |
- Resistant to oils, greases |
- Versatile, suitable for various industrial applications |
Aerospace and Defense, Automotive, Consumer Products, Oil and Gas |
|
Nylon 6 |
- High impact strength |
- Density: 1.14 g/cm³ |
- Resistant to moisture, abrasion |
- Durable, excellent for applications requiring impact resistance |
Automotive, Consumer Products |
|
PA 12 Glass Beads |
- Improved stiffness and dimensional stability |
- Density: Varies by formulation |
- Reinforced with glass beads |
- Increased stiffness, suitable for engineering applications |
Automotive, Aerospace and Defense |
|
PC-ISO |
- High strength and heat resistance |
- Density: Varies by formulation |
- Biocompatible |
- Suitable for medical and aerospace applications |
Aerospace and Defense, Medical |
|
PC+ABS |
- Good impact resistance |
- Density: Varies by formulation |
- Resistant to chemicals |
- Blends properties of PC and ABS, versatile material |
Automotive, Consumer Products |
|
PETG |
- Excellent transparency and impact resistance |
- Density: 1.27 g/cm³ |
- Food-safe, BPA-free |
- Clarity and toughness, ideal for packaging and displays |
Consumer Products, Medical |
|
PLA |
- Biodegradable and easy to print |
- Density: 1.24 g/cm³ |
- Biodegradable |
- Eco-friendly, easy to 3D print |
Consumer Products, Medical |
|
Polycarbonate (PC) |
- High impact resistance, optical clarity |
- Density: 1.20 g/cm³ |
- Excellent optical properties |
- Exceptional clarity and strength, suitable for transparent parts |
Aerospace and Defense, Consumer Products, Medical |
|
Polypropylene |
- Low density and good chemical resistance |
- Density: 0.90 g/cm³ |
- Resistant to moisture, chemicals |
- Lightweight, suitable for low-stress applications |
Consumer Products, Automotive |
|
Rubber-Like |
- Flexible and rubber-like properties |
- Density: Varies by formulation |
- Flexible elastomer |
- Mimics rubber, suitable for gaskets and seals |
Automotive, Consumer Products |
|
Somos Evolve |
- High strength and heat resistance |
- Density: Varies by formulation |
- Photopolymer |
- Engineering-grade material, suitable for functional prototypes |
Aerospace and Defense, Automotive |
|
Somos PerFORM |
- High stiffness and heat resistance |
- Density: Varies by formulation |
- Photopolymer |
- Strong and stiff, ideal for high-temperature applications |
Aerospace and Defense |
|
Somos Waterclear |
- High transparency and clarity |
- Density: Varies by formulation |
- Photopolymer |
- Transparent, suitable for clear prototypes and parts |
Consumer Products, Medical |
|
Somos Watershed |
- Excellent clarity and water resistance |
- Density: Varies by formulation |
- Photopolymer |
- Waterproof, suitable for water-resistant parts |
Consumer Products, Medical |
|
ST-130 |
- High toughness and durability |
- Density: Varies by formulation |
- Photopolymer |
- Rigid, tough, and durable, good for functional prototypes |
Consumer Products, Aerospace and Defense |
|
TPU 88A |
- Flexible and elastomeric properties |
- Density: Varies by formulation |
- Thermoplastic polyurethane |
- Flexibility and resilience, suitable for elastomeric parts |
Automotive, Consumer Products, Medical |
|
Ultem 1010 |
- High strength, heat, and chemical resistance |
- Density: 1.27 g/cm³ |
- Flame-resistant, UL 94 V0 |
- Engineering-grade thermoplastic with excellent properties |
Aerospace and Defense, Automotive, Oil and Gas |
|
Ultem 9085 |
- High strength, heat, and chemical resistance |
- Density: 1.27 g/cm³ |
- Flame-resistant, UL 94 V0 |
- Suitable for aerospace and transportation applications |
Aerospace and Defense, Automotive |
|
Vero |
- Rigid and durable |
- Density: Varies by formulation |
- Photopolymer |
- Versatile material, good for prototypes and models |
Consumer Products, Aerospace and Defense |
|
VeroClear |
- High transparency and clarity |
- Density: Varies by formulation |
- Photopolymer |
- Transparent appearance, ideal for clear parts |
Consumer Products, Medical |
PrintForm, LLC
3423 Piedmont Rd NE, Atlanta, GA 30305, USA
:(404) 999-4916
:(404) 937-6257
: info@printform.com
