When Prototypes Fail in Production
- and How to Prevent It

A medical device startup spent eight months perfecting their prototypes. The design won awards. Investors lined up. Then they scaled to production, and the failure rate hit 40 percent.

The prototype worked flawlessly in controlled conditions. But production introduced variables they hadn’t tested: different material batches, assembly line speeds, operator variations, temperature fluctuations during shipping. What succeeded in a lab of five units collapsed at five thousand.

This isn’t rare. It’s predictable.

The Gap Between Prototype and Production

Prototypes exist to prove concepts. They answer: Can this work? Production asks a harder question: Can this work consistently, affordably, at scale?

Most teams treat prototyping as a linear process. Build the prototype, test it, then hand it to manufacturing. But that handoff is where things break. The prototype used custom machining. Production needs injection molding. The prototype had hand-soldered connections. Production requires automated assembly. Different processes, different tolerances, different failure modes.

Boeing’s 787 Dreamliner faced this during development. Suppliers built prototype components that met specifications individually but created assembly issues at scale. Fasteners didn’t align. Sections arrived with different dimensional tolerances. Production delays stretched years because prototype-level precision didn’t translate to manufacturing reality.

Where Prototypes Actually Fail

1. Material inconsistency kills scalability.

Your prototype might use a specific batch of polymer that behaves perfectly. Production sources materials from multiple suppliers across quarters or years. Slight variations in composition, moisture content, or processing change everything from tensile strength to surface finish.

2. Tolerance stack-up compounds in assembly.

A prototype with five components might work fine with loose tolerances. Add twenty components in production, and those tolerances stack. What seemed like acceptable variation becomes misalignment, binding, or complete failure to assemble.

3. Environmental factors emerge under volume.

Heat from continuous operation. Vibration during bulk shipping. Humidity in different facilities. Storage time before use. Prototypes rarely face these conditions. Production units live in them.

What we’re seeing across programs: teams that validate under production conditions early cut their time to market by 30 to 40 percent. They don’t prototype in isolation. They prototype for manufacturing from day one.

CNC Materials

1. Stainless steel

A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.

2. Ren

A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.

3. POM (Acetol)

A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.

4. Polycarbonate

An impact-resistant and transparent material often CNC machined into parts like safety goggles, electronic enclosures, and automotive lighting covers due to its excellent strength and optical clarity.

5. PMMA (Acrylic)

A lightweight and transparent material commonly CNC machined into parts like display panels, signage, and lenses due to its optical clarity, UV resistance, and ease of machining.

6. Nylon

A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.

7.Aluminum

A lightweight and versatile material widely used for CNC machining parts such as housings, brackets, and heat sinks due to its high strength-to-weight ratio, excellent thermal conductivity, and corrosion resistance.

8. ABS

A durable and impact-resistant thermoplastic commonly CNC machined into parts like prototypes, enclosures, and consumer goods due to its good mechanical properties, ease of machining, and wide range of available colors.

9.Brass

A metal alloy known for its excellent machinability and corrosion resistance, often CNC machined into parts like fittings, valves, and decorative components due to its aesthetic appeal and durability.

10. Copper

A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.

11. Mild Steel

A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.

12. Magnesium

A lightweight metal used for CNC machining parts like aerospace components, electronic housings, and automotive parts due to its high strength-to-weight ratio, excellent machinability, and good thermal conductivity.

13. Foam

A lightweight and versatile material used for CNC machining applications like packaging inserts, architectural models, and signage due to its ease of machining, low density, and impact-absorbing properties.

14. Delrin

A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.

1. Stainless steel

A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.

2. Ren

A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.

3. POM (Acetol)

A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.

4. Polycarbonate

5. PMMA (Acrylic)

A lightweight and transparent material commonly CNC machined into parts like display panels, signage, and lenses due to its optical clarity, UV resistance, and ease of machining.

6. Nylon

A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.

7.Aluminum

8. ABS

9.Brass

10. Copper

A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.

11. Mild Steel

A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.

12. Magnesium

13. Foam

14. Delrin

A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.

Material	Mechanical Properties	Physical Properties	Chemical Properties	Features	Common Applications
High Temp PC Like	Tensile Strength: 60-70 MPa Impact Strength: 10-20 kJ/m² Heat Deflection Temperature: 135-150°C	Transparent or translucent Good dimensional stability	Resistant to many chemicals and oils	Excellent transparency High temperature resistance	Aerospace and Defense: Transparent canopies, Medical: Medical device components
High Temp ABS Like	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Heat Deflection Temperature: 100-120°C	Various colors available Good dimensional stability	Resistant to many chemicals and oils	Suitable for high-temperature applications	Aerospace and Defense: Engine components, Automotive: Engine components
High Strength ABS Like	Tensile Strength: 60-80 MPa Impact Strength: 20-40 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	Various colors available Low density Good dimensional stability	Resistant to many chemicals and oils	High strength and impact resistance Lightweight	Automotive: Bumpers, Aerospace and Defense: Structural components
ABS Like Gray	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	Gray color Low density Good dimensional stability	Resistant to many chemicals and oils	Gray appearance Lightweight Durable	Automotive: Interior components, consumer products: casings, fittings
ABS Like Black	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	Black color Low density Good dimensional stability	Resistant to many chemicals and oils	Black appearance Lightweight - Durable	Consumer Products: Electronics casings, automotive interior parts
ABS Like White	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	White color Low density Good dimensional stability	Resistant to many chemicals and oils	White appearance Lightweight Durable	Consumer Products: Electronics casings, toys, kitchen appliances
ABS	Good impact resistance	Density: 1.03 g/cm³	Resistant to diluted acids, alkalis	High strength, versatility, cost-effective	Automotive, Consumer Products
ABS – M30i	- Good tensile strength	- Density: 1.04 g/cm³	- Medical grade	- Biocompatible, sterilizable, suitable for medical devices	Medical
ABS ESD	- Static-dissipative properties	- Density: 1.06 g/cm³	- ESD protection	- Prevents electrostatic discharge, suitable for electronics	Aerospace and Defense, Consumer Products
ABS-Like	- High toughness and durability	- Density: Varies by formulation	- Resistant to various chemicals	- Resembles ABS but may offer specific improvements	Varies by formulation
Accura 25	- High accuracy and resolution	- Density: Varies by formulation	- Photopolymer	- Used in stereolithography 3D printing, fine details	Consumer Products, Medical, Aerospace and Defense
Accura 60	- High strength and durability	- Density: Varies by formulation	- Photopolymer	- Tough and durable, suitable for functional prototypes	Consumer Products, Aerospace and Defense
Accura AMX Rigid Black	- High impact resistance	- Density: Varies by formulation	- Photopolymer	- Rigid and durable, good for functional prototypes	Consumer Products, Aerospace and Defense
Accura ClearVue	- High transparency and clarity	- Density: Varies by formulation	- Photopolymer	- Crystal clear appearance, ideal for clear parts	Consumer Products, Medical
Accura Xtreme Grey/White	- High toughness and durability	- Density: Varies by formulation	- Photopolymer	- Resistant to high temperatures, strong and rigid	Consumer Products, Aerospace and Defense
ASA	- Excellent UV resistance	- Density: 1.07 g/cm³	- Weather-resistant	- Outdoor durability, retains color and strength in sunlight	Automotive, Consumer Products
Nylon	- High tensile strength	- Density: 1.15 g/cm³	- Resistant to moisture, chemicals	- Tough and durable, suitable for functional parts	Aerospace and Defense, Automotive, Consumer Products
Nylon 11 Flame Retardant	- Flame retardant properties	- Density: Varies by formulation	- Flame-resistant	- Fire safety, suitable for applications requiring flame resistance	Aerospace and Defense, Automotive
Nylon 12	- Good chemical resistance	- Density: 1.02 g/cm³	- Resistant to oils, greases	- Versatile, suitable for various industrial applications	Aerospace and Defense, Automotive, Consumer Products, Oil and Gas
Nylon 6	- High impact strength	- Density: 1.14 g/cm³	- Resistant to moisture, abrasion	- Durable, excellent for applications requiring impact resistance	Automotive, Consumer Products
PA 12 Glass Beads	- Improved stiffness and dimensional stability	- Density: Varies by formulation	- Reinforced with glass beads	- Increased stiffness, suitable for engineering applications	Automotive, Aerospace and Defense
PC-ISO	- High strength and heat resistance	- Density: Varies by formulation	- Biocompatible	- Suitable for medical and aerospace applications	Aerospace and Defense, Medical
PC+ABS	- Good impact resistance	- Density: Varies by formulation	- Resistant to chemicals	- Blends properties of PC and ABS, versatile material	Automotive, Consumer Products
PETG	- Excellent transparency and impact resistance	- Density: 1.27 g/cm³	- Food-safe, BPA-free	- Clarity and toughness, ideal for packaging and displays	Consumer Products, Medical
PLA	- Biodegradable and easy to print	- Density: 1.24 g/cm³	- Biodegradable	- Eco-friendly, easy to 3D print	Consumer Products, Medical
Polycarbonate (PC)	- High impact resistance, optical clarity	- Density: 1.20 g/cm³	- Excellent optical properties	- Exceptional clarity and strength, suitable for transparent parts	Aerospace and Defense, Consumer Products, Medical
Polypropylene	- Low density and good chemical resistance	- Density: 0.90 g/cm³	- Resistant to moisture, chemicals	- Lightweight, suitable for low-stress applications	Consumer Products, Automotive
Rubber-Like	- Flexible and rubber-like properties	- Density: Varies by formulation	- Flexible elastomer	- Mimics rubber, suitable for gaskets and seals	Automotive, Consumer Products
Somos Evolve	- High strength and heat resistance	- Density: Varies by formulation	- Photopolymer	- Engineering-grade material, suitable for functional prototypes	Aerospace and Defense, Automotive
Somos PerFORM	- High stiffness and heat resistance	- Density: Varies by formulation	- Photopolymer	- Strong and stiff, ideal for high-temperature applications	Aerospace and Defense
Somos Waterclear	- High transparency and clarity	- Density: Varies by formulation	- Photopolymer	- Transparent, suitable for clear prototypes and parts	Consumer Products, Medical
Somos Watershed	- Excellent clarity and water resistance	- Density: Varies by formulation	- Photopolymer	- Waterproof, suitable for water-resistant parts	Consumer Products, Medical
ST-130	- High toughness and durability	- Density: Varies by formulation	- Photopolymer	- Rigid, tough, and durable, good for functional prototypes	Consumer Products, Aerospace and Defense
TPU 88A	- Flexible and elastomeric properties	- Density: Varies by formulation	- Thermoplastic polyurethane	- Flexibility and resilience, suitable for elastomeric parts	Automotive, Consumer Products, Medical
Ultem 1010	- High strength, heat, and chemical resistance	- Density: 1.27 g/cm³	- Flame-resistant, UL 94 V0	- Engineering-grade thermoplastic with excellent properties	Aerospace and Defense, Automotive, Oil and Gas
Ultem 9085	- High strength, heat, and chemical resistance	- Density: 1.27 g/cm³	- Flame-resistant, UL 94 V0	- Suitable for aerospace and transportation applications	Aerospace and Defense, Automotive
Vero	- Rigid and durable	- Density: Varies by formulation	- Photopolymer	- Versatile material, good for prototypes and models	Consumer Products, Aerospace and Defense
VeroClear	- High transparency and clarity	- Density: Varies by formulation	- Photopolymer	- Transparent appearance, ideal for clear parts	Consumer Products, Medical

CNC Finishes

Anodizing: An electrochemical process that enhances the surface of metal parts with a protective oxide layer, offering increased corrosion resistance and improved aesthetics. It is preferred for aluminum parts that require durability, color options, and resistance to wear and weathering.
Painting: The application of a protective coating on CNC machined parts to provide aesthetic appeal, color customization, and added protection against corrosion. It is preferred when parts require specific colors, branding, or a decorative finish.
Pad Printing: A printing technique where ink is transferred from a silicone pad onto CNC machined parts, allowing for detailed and precise graphics, text, or logos to be applied. It is preferred when parts require intricate designs, branding, or labeling.
Sanding and Polishing: The process of smoothing the surface of CNC machined parts through abrasion to achieve a desired finish. It is preferred when parts require a smooth, glossy, or reflective surface for aesthetics, improved functionality, or ease of cleaning.
Vapor Polishing: A process that involves exposing CNC machined parts to vaporized solvents, resulting in the surface being melted and re-solidified, producing a high-gloss finish. It is preferred for transparent or clear parts, such as acrylic or polycarbonate, when a glossy and optically clear finish is desired.
Blasting: The use of abrasive materials, such as sand or glass beads, to remove surface imperfections, burrs, or scale from CNC machined parts, resulting in a uniform texture or a matte finish. It is preferred when parts require a textured appearance, improved adhesion for coatings, or to remove sharp edges or burrs.

CNC Parts

1. Aerospace and Defense

- Aircraft components: Wings, fuselage, landing gear.
- Engine parts: Turbine blades, combustion chambers, fuel nozzles.
- Aerospace fasteners: Bolts, nuts, rivets.
- Missile components: Guidance systems, rocket motors, warhead casings.
- Defense system parts: Gun barrels, ammunition casings, armored vehicle components.

2. Automotive

- Engine components: Cylinder heads, pistons, crankshafts.
- Transmission parts: Gears, shafts, synchronizers.
- Brackets and mounts: Engine mounts, suspension brackets.
- Interior trim parts: Dashboard components, door panels.
- Automotive lighting housings: Headlight assemblies, taillight covers.

3. Consumer Products

- Electronic enclosures: Housing for electronic devices, control panels.
- Appliance components: Handles, knobs, control buttons.
- Custom knobs and handles: Decorative or functional knobs and handles.
- Decorative accessories: Ornaments, figurines, jewelry components.
- Personal care product components: Cosmetic containers, toothbrush handles.

4. Energy

- Turbine parts: Blades, vanes, rotor discs.
- Pump and valve components: Impellers, valve bodies, seals.
- Heat exchanger parts: Tubes, fins, headers.
- Solar panel components: Mounting brackets, frames, junction boxes.
- Electrical connectors: Cable connectors, terminal blocks, sockets.

5. Medical

- Surgical instruments: Forceps, scalpels, retractors.
- Implantable device components: Joint implants, pacemaker components.
- Prosthetic parts: Limb sockets, joint components.
- Medical equipment housings: Casing for diagnostic equipment, monitors.
- Dental appliance components: Denture frames, orthodontic brackets.

6. Oil and Gas

- Drilling tool components: Drill bits, drill collars, stabilizers.
- Valve bodies and seats: Gate valves, ball valves, control valves.
- Pump parts: Impellers, casings, seals.
- Subsea connectors: Couplings, connectors, riser systems.
- Pipeline fittings and flanges: Flange connections, pipe connectors, pipeline supports.

Aerospace and defence

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Gaskets and Seals
When Prototypes Fail in Production – and How to Prevent It Interior Components
When Prototypes Fail in Production – and How to Prevent It Shock Absorbers
When Prototypes Fail in Production – and How to Prevent It Engine Components
When Prototypes Fail in Production – and How to Prevent It Drones and UAVs

Engine Seal, Cargo Door Seal, Hydraulic System Seal, Landing Gear Door Seal and Fuselage Joint Seal

Armrest, Tray Table, Seat Cushion, Overhead Console, Window Frame, Headrest and Lavatory Fixture

Helicopter Skid Shock Absorber, Cockpit Seat Shock Absorber, Cargo Ramp Shock Absorber, Parachute Landing Shock Absorber, Nose Wheel Strut and Main Landing Gear Strut

Turbine Blade, Combustion Chamber Liner, Thrust Reverser Component, Fuel Nozzle, Engine Mount Isolator, Exhaust Duct Liner, Intake Manifold Gasket, Heat Shield, Engine Baffle Seal and Ignition Coil Boot

Drone Frame, Landing Gear Leg, Propeller Guard, Camera Mount, GPS Antenna Enclosure, Gimbal Stabilizer, Motor Mount Bracket and Arm Reinforcement Plate

Automotive

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Suspension Bushings
When Prototypes Fail in Production – and How to Prevent It Bump Stops
When Prototypes Fail in Production – and How to Prevent It Interior Trim
When Prototypes Fail in Production – and How to Prevent It Body Kits
When Prototypes Fail in Production – and How to Prevent It Tire Treads

Front Lower Control Arm Bushing, Rear Upper Control Arm Bushing, Sway Bar Bushing, Subframe Bushing, Strut Mount Bushing, Leaf Spring Bushing, Tie Rod End Bushing, Trailing Arm Bushing, Stabilizer Bar Bushing and Steering Rack Bushing

Front Bump Stop, Rear Bump Stop, Strut Bump Stop, Coil Spring Bump Stop, Shock Absorber Bump Stop, Sway Bar Bump Stop and Axle Bump Stop

Dashboard Panel Trim, Door Panel Insert, Cup Holder Trim, Headliner Trim, Seat Back Panel and Glove Compartment Trim

Front Bumper Spoiler, Rear Bumper Diffuser, Side Skirts, Fender Flares, Hood Scoop, Roof Spoiler and Front Lip Spoiler

Forklift Front Tire Tread, Forklift Rear Tire Tread, Industrial Vehicle Rear Tire Tread, Warehouse Equipment Tire Tread, Lawn Tractor Tire Tread and Material Handling Equipment Tire Tread

Design for Manufacturing from the Start

The phrase sounds bureaucratic. It’s not. It means involving manufacturing engineers before you finalize the prototype design. Ask: Can this geometry be molded? Will this tolerance hold across ten thousand units? Does this assembly sequence make sense on a line?

Apple’s unibody MacBook design emerged from this thinking. Previous laptop designs used dozens of parts screwed together. The unibody carved the chassis from a single aluminum block. Fewer parts meant fewer failure points, faster assembly, tighter tolerances, and better structural integrity. The prototype directly anticipated production constraints.

Run your prototype through production processes, even in small batches. If you’re planning injection molding, test with molded parts early, not just machined ones. If assembly will be automated, simulate that automation in your validation. Surface-level testing won’t catch what actual production reveals.

Validation That Matters

Functional testing proves the design works. Production validation proves it works repeatedly under real conditions. That means:

Testing with production-intent materials and processes
Running extended durability trials that mirror actual use
Building qualification batches before full production
Documenting failure modes and addressing root causes

NASA’s approach to spaceflight hardware offers a template. Every component goes through qualification testing that exceeds expected flight conditions. Then they build flight units using identical processes and materials. Only after those flight units pass acceptance testing do they launch. It’s expensive upfront. It’s cheaper than failure.

Making the Transition

Start your prototype with manufacturing in mind. Use (DFM) design for manufacturing principles from the first sketch. Involve suppliers and manufacturing partners early. Run pilot production before committing to volume. Document everything: materials, processes, test results, failure modes.

The gap between prototype and production isn’t inevitable. It’s a design choice. Teams that bridge it early don’t just avoid costly failures. They build products that scale reliably from the first production run.

Your prototype proves it can work. Production proves it will work. Design for both from the beginning.

Partner with Manufacturing Experts Who Understand Both Worlds

At PrintForm, we’ve guided hundreds of products through the prototype-to-production transition. We don’t just manufacture parts. We help you design prototypes that are built for scalability from the first iteration.

Our engineering team reviews designs for manufacturability before you commit to tooling. We identify tolerance issues, material considerations, and process constraints while changes are still inexpensive. We run pilot batches using production-intent processes so you can validate performance under real conditions, not lab conditions.

Whether you’re developing medical devices, consumer products, or industrial components, we bring 30+ years of injection molding expertise to your prototype phase. We’ve seen what fails at scale and how to prevent it.

Ready to bridge the gap between prototype and production? Contact PrintForm to discuss your project. Let’s build something that works in the lab and thrives on the production floor.

Consumer Products

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Footwear
When Prototypes Fail in Production – and How to Prevent It Toys and Games
When Prototypes Fail in Production – and How to Prevent It Appliance Handles
When Prototypes Fail in Production – and How to Prevent It Sporting Goods
When Prototypes Fail in Production – and How to Prevent It Personalized Promotional Items

Shoe Insoles, Shoe Outsoles, Shoe Midsoles, Heel Cushions, Arch Support Inserts and Shoelaces

Action figure parts, Puzzle pieces, Board game components, Toy car bodies and Doll accessories

DALL·E 2023-08-11 10.38.45 - Razor handle

Refrigerator Door Handle, Dishwasher Door Handle, Toaster Handle and Kitchen Appliance Drawer Handle

Tennis Racket Grip, Golf Club Grips, Bicycle Handlebar Grips, Fishing Rod Handles, Ski Pole Grips, Bowling Ball Finger Inserts and Ping Pong Paddle Grips

Branded keychains, Customized USB drives, Logo-bearing pens, Promotional event giveaways, Custom phone stands, Business card holders, Unique promotional trophies, Customized badges and buttons, Drink coasters with logos and Event-specific 3D printed gifts

Energy

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Oil Seals
When Prototypes Fail in Production – and How to Prevent It Hydroelectric Turbine Components
When Prototypes Fail in Production – and How to Prevent It Solar Panel Encapsulants
When Prototypes Fail in Production – and How to Prevent It Wind Turbine Components
When Prototypes Fail in Production – and How to Prevent It Battery Enclosures

Pump Shaft Seal, Compressor Piston Seal, Valve Stem Seal, Crankshaft Seal, Transmission Input Shaft Seal, Hydraulic Cylinder Seal, Gearbox Output Seal, Oil Cooler Seal, Gas Turbine Seal and Wellhead Seal

Turbine Blade, Runner Hub, Wicket Gate, Generator Stator, Penstock Liner, Draft Tube, Turbine Bearing, Blade Pitch Control Arm, Guide Vane and Turbine Nozzle

Solar Cell Encapsulation Sheet, Frame Gasket and Busbar Encapsulation

Wind Turbine Blade, Pitch Bearing Seal, Mainshaft Bearing, Rotor Hub, Gearbox Breather Plug and Tower Flange Gasket

Battery Terminal Cover, Ventilation Grommet, Battery Rack Enclosure, Cable Entry Grommet, Busbar Insulator and Battery Module Housing

Medical

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Medical Device Grips
When Prototypes Fail in Production – and How to Prevent It Prosthetic Limbs
When Prototypes Fail in Production – and How to Prevent It Medical Equipment Housings
When Prototypes Fail in Production – and How to Prevent It Orthopedic Braces
When Prototypes Fail in Production – and How to Prevent It Dental Models

Surgical Scissor Handle, Endoscope Control Knob, Blood Pressure Cuff Bulb, Ultrasound Probe Handle, Electrode Holder Grip and Insulin Pen Handle

Prosthetic Foot Sole, Shin Tube, Ankle Component, Suspension Sleeve and Cosmetic Cover

Anesthesia Machine Enclosure, Medical Cart Housing, Blood Analyzer Casing, MRI Machine Enclosure and Ventilator Housing

Elbow Brace Pad, Patella Stabilizer Brace and Lumbar Support Brace

Tooth Model Crown, Gingiva Model, Dental Bridge Model, Implant Model, Orthodontic Appliance Model, Bite Registration Model, Study Cast and Wax Bite Rim Model

Oil and Gas

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Valve Seals
When Prototypes Fail in Production – and How to Prevent It Pipe Linings
When Prototypes Fail in Production – and How to Prevent It Offshore Equipment Components
When Prototypes Fail in Production – and How to Prevent It Pump Components
When Prototypes Fail in Production – and How to Prevent It Subsea Connectors

Gate Valve Seal, Ball Valve Seat, Butterfly Valve Seal, Plug Valve Seal, Check Valve Seal, Pressure Relief Valve Seal, Globe Valve Seal, Choke Valve Seat, Diaphragm Valve Seal and Control Valve Plug Seal

Pipeline Lining Sleeve, Pipe Bend Lining, Pipe Elbow Lining, Pipe Reducer Lining, Pipe Tee Lining, Pipe Flange Lining, Pipe Coupling Lining, Pipe Cross Lining, Pipe Transition Lining aaand Pipe Spool Lining

Offshore Platform Leg Pad, Subsea Umbilical Clamp, ROV (Remotely Operated Vehicle) Component, Offshore Crane Bushing, Subsea Cable Connector Seal, Offshore Buoyancy Module, Underwater Pipelaying Equipment Part, Offshore Anchor Block, Platform Mooring Component and Offshore Pipeline Pigging Component

Pump Impeller, Pump Volute, Pump Shaft Sleeve, Pump Wear Ring, Pump Casing, Pump Diffuser, Pump Coupling, Pump Suction Bell and Pump Discharge Nozzle

Subsea Electrical Connector, Subsea Hydraulic Connector, Subsea Fiber Optic Connector, Subsea Instrumentation Connector, Subsea Pressure Sensor Connector, Subsea Control System Connector, Subsea Wellhead Connector, Subsea Pipeline Connector, Subsea Manifold Connector and Subsea ROV Connector

CNC Materials

1. Stainless steel

A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.

2. Ren

A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.

3. POM (Acetol)

A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.

4. Polycarbonate

5. PMMA (Acrylic)

A lightweight and transparent material commonly CNC machined into parts like display panels, signage, and lenses due to its optical clarity, UV resistance, and ease of machining.

6. Nylon

A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.

7.Aluminum

8. ABS

9.Brass

10. Copper

A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.

11. Mild Steel

A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.

12. Magnesium

13. Foam

14. Delrin

A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.

1. Stainless steel

A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.

2. Ren

A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.

3. POM (Acetol)

A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.

4. Polycarbonate

5. PMMA (Acrylic)

A lightweight and transparent material commonly CNC machined into parts like display panels, signage, and lenses due to its optical clarity, UV resistance, and ease of machining.

6. Nylon

A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.

7.Aluminum

8. ABS

9.Brass

10. Copper

A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.

11. Mild Steel

A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.

12. Magnesium

13. Foam

14. Delrin

A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.

Material	Mechanical Properties	Physical Properties	Chemical Properties	Features	Common Applications
High Temp PC Like	Tensile Strength: 60-70 MPa Impact Strength: 10-20 kJ/m² Heat Deflection Temperature: 135-150°C	Transparent or translucent Good dimensional stability	Resistant to many chemicals and oils	Excellent transparency High temperature resistance	Aerospace and Defense: Transparent canopies, Medical: Medical device components
High Temp ABS Like	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Heat Deflection Temperature: 100-120°C	Various colors available Good dimensional stability	Resistant to many chemicals and oils	Suitable for high-temperature applications	Aerospace and Defense: Engine components, Automotive: Engine components
High Strength ABS Like	Tensile Strength: 60-80 MPa Impact Strength: 20-40 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	Various colors available Low density Good dimensional stability	Resistant to many chemicals and oils	High strength and impact resistance Lightweight	Automotive: Bumpers, Aerospace and Defense: Structural components
ABS Like Gray	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	Gray color Low density Good dimensional stability	Resistant to many chemicals and oils	Gray appearance Lightweight Durable	Automotive: Interior components, consumer products: casings, fittings
ABS Like Black	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	Black color Low density Good dimensional stability	Resistant to many chemicals and oils	Black appearance Lightweight - Durable	Consumer Products: Electronics casings, automotive interior parts
ABS Like White	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	White color Low density Good dimensional stability	Resistant to many chemicals and oils	White appearance Lightweight Durable	Consumer Products: Electronics casings, toys, kitchen appliances
ABS	Good impact resistance	Density: 1.03 g/cm³	Resistant to diluted acids, alkalis	High strength, versatility, cost-effective	Automotive, Consumer Products
ABS – M30i	- Good tensile strength	- Density: 1.04 g/cm³	- Medical grade	- Biocompatible, sterilizable, suitable for medical devices	Medical
ABS ESD	- Static-dissipative properties	- Density: 1.06 g/cm³	- ESD protection	- Prevents electrostatic discharge, suitable for electronics	Aerospace and Defense, Consumer Products
ABS-Like	- High toughness and durability	- Density: Varies by formulation	- Resistant to various chemicals	- Resembles ABS but may offer specific improvements	Varies by formulation
Accura 25	- High accuracy and resolution	- Density: Varies by formulation	- Photopolymer	- Used in stereolithography 3D printing, fine details	Consumer Products, Medical, Aerospace and Defense
Accura 60	- High strength and durability	- Density: Varies by formulation	- Photopolymer	- Tough and durable, suitable for functional prototypes	Consumer Products, Aerospace and Defense
Accura AMX Rigid Black	- High impact resistance	- Density: Varies by formulation	- Photopolymer	- Rigid and durable, good for functional prototypes	Consumer Products, Aerospace and Defense
Accura ClearVue	- High transparency and clarity	- Density: Varies by formulation	- Photopolymer	- Crystal clear appearance, ideal for clear parts	Consumer Products, Medical
Accura Xtreme Grey/White	- High toughness and durability	- Density: Varies by formulation	- Photopolymer	- Resistant to high temperatures, strong and rigid	Consumer Products, Aerospace and Defense
ASA	- Excellent UV resistance	- Density: 1.07 g/cm³	- Weather-resistant	- Outdoor durability, retains color and strength in sunlight	Automotive, Consumer Products
Nylon	- High tensile strength	- Density: 1.15 g/cm³	- Resistant to moisture, chemicals	- Tough and durable, suitable for functional parts	Aerospace and Defense, Automotive, Consumer Products
Nylon 11 Flame Retardant	- Flame retardant properties	- Density: Varies by formulation	- Flame-resistant	- Fire safety, suitable for applications requiring flame resistance	Aerospace and Defense, Automotive
Nylon 12	- Good chemical resistance	- Density: 1.02 g/cm³	- Resistant to oils, greases	- Versatile, suitable for various industrial applications	Aerospace and Defense, Automotive, Consumer Products, Oil and Gas
Nylon 6	- High impact strength	- Density: 1.14 g/cm³	- Resistant to moisture, abrasion	- Durable, excellent for applications requiring impact resistance	Automotive, Consumer Products
PA 12 Glass Beads	- Improved stiffness and dimensional stability	- Density: Varies by formulation	- Reinforced with glass beads	- Increased stiffness, suitable for engineering applications	Automotive, Aerospace and Defense
PC-ISO	- High strength and heat resistance	- Density: Varies by formulation	- Biocompatible	- Suitable for medical and aerospace applications	Aerospace and Defense, Medical
PC+ABS	- Good impact resistance	- Density: Varies by formulation	- Resistant to chemicals	- Blends properties of PC and ABS, versatile material	Automotive, Consumer Products
PETG	- Excellent transparency and impact resistance	- Density: 1.27 g/cm³	- Food-safe, BPA-free	- Clarity and toughness, ideal for packaging and displays	Consumer Products, Medical
PLA	- Biodegradable and easy to print	- Density: 1.24 g/cm³	- Biodegradable	- Eco-friendly, easy to 3D print	Consumer Products, Medical
Polycarbonate (PC)	- High impact resistance, optical clarity	- Density: 1.20 g/cm³	- Excellent optical properties	- Exceptional clarity and strength, suitable for transparent parts	Aerospace and Defense, Consumer Products, Medical
Polypropylene	- Low density and good chemical resistance	- Density: 0.90 g/cm³	- Resistant to moisture, chemicals	- Lightweight, suitable for low-stress applications	Consumer Products, Automotive
Rubber-Like	- Flexible and rubber-like properties	- Density: Varies by formulation	- Flexible elastomer	- Mimics rubber, suitable for gaskets and seals	Automotive, Consumer Products
Somos Evolve	- High strength and heat resistance	- Density: Varies by formulation	- Photopolymer	- Engineering-grade material, suitable for functional prototypes	Aerospace and Defense, Automotive
Somos PerFORM	- High stiffness and heat resistance	- Density: Varies by formulation	- Photopolymer	- Strong and stiff, ideal for high-temperature applications	Aerospace and Defense
Somos Waterclear	- High transparency and clarity	- Density: Varies by formulation	- Photopolymer	- Transparent, suitable for clear prototypes and parts	Consumer Products, Medical
Somos Watershed	- Excellent clarity and water resistance	- Density: Varies by formulation	- Photopolymer	- Waterproof, suitable for water-resistant parts	Consumer Products, Medical
ST-130	- High toughness and durability	- Density: Varies by formulation	- Photopolymer	- Rigid, tough, and durable, good for functional prototypes	Consumer Products, Aerospace and Defense
TPU 88A	- Flexible and elastomeric properties	- Density: Varies by formulation	- Thermoplastic polyurethane	- Flexibility and resilience, suitable for elastomeric parts	Automotive, Consumer Products, Medical
Ultem 1010	- High strength, heat, and chemical resistance	- Density: 1.27 g/cm³	- Flame-resistant, UL 94 V0	- Engineering-grade thermoplastic with excellent properties	Aerospace and Defense, Automotive, Oil and Gas
Ultem 9085	- High strength, heat, and chemical resistance	- Density: 1.27 g/cm³	- Flame-resistant, UL 94 V0	- Suitable for aerospace and transportation applications	Aerospace and Defense, Automotive
Vero	- Rigid and durable	- Density: Varies by formulation	- Photopolymer	- Versatile material, good for prototypes and models	Consumer Products, Aerospace and Defense
VeroClear	- High transparency and clarity	- Density: Varies by formulation	- Photopolymer	- Transparent appearance, ideal for clear parts	Consumer Products, Medical

CNC Finishes

Anodizing: An electrochemical process that enhances the surface of metal parts with a protective oxide layer, offering increased corrosion resistance and improved aesthetics. It is preferred for aluminum parts that require durability, color options, and resistance to wear and weathering.
Painting: The application of a protective coating on CNC machined parts to provide aesthetic appeal, color customization, and added protection against corrosion. It is preferred when parts require specific colors, branding, or a decorative finish.
Pad Printing: A printing technique where ink is transferred from a silicone pad onto CNC machined parts, allowing for detailed and precise graphics, text, or logos to be applied. It is preferred when parts require intricate designs, branding, or labeling.
Sanding and Polishing: The process of smoothing the surface of CNC machined parts through abrasion to achieve a desired finish. It is preferred when parts require a smooth, glossy, or reflective surface for aesthetics, improved functionality, or ease of cleaning.
Vapor Polishing: A process that involves exposing CNC machined parts to vaporized solvents, resulting in the surface being melted and re-solidified, producing a high-gloss finish. It is preferred for transparent or clear parts, such as acrylic or polycarbonate, when a glossy and optically clear finish is desired.
Blasting: The use of abrasive materials, such as sand or glass beads, to remove surface imperfections, burrs, or scale from CNC machined parts, resulting in a uniform texture or a matte finish. It is preferred when parts require a textured appearance, improved adhesion for coatings, or to remove sharp edges or burrs.

CNC Parts

1. Aerospace and Defense

- Aircraft components: Wings, fuselage, landing gear.
- Engine parts: Turbine blades, combustion chambers, fuel nozzles.
- Aerospace fasteners: Bolts, nuts, rivets.
- Missile components: Guidance systems, rocket motors, warhead casings.
- Defense system parts: Gun barrels, ammunition casings, armored vehicle components.

2. Automotive

- Engine components: Cylinder heads, pistons, crankshafts.
- Transmission parts: Gears, shafts, synchronizers.
- Brackets and mounts: Engine mounts, suspension brackets.
- Interior trim parts: Dashboard components, door panels.
- Automotive lighting housings: Headlight assemblies, taillight covers.

3. Consumer Products

- Electronic enclosures: Housing for electronic devices, control panels.
- Appliance components: Handles, knobs, control buttons.
- Custom knobs and handles: Decorative or functional knobs and handles.
- Decorative accessories: Ornaments, figurines, jewelry components.
- Personal care product components: Cosmetic containers, toothbrush handles.

4. Energy

- Turbine parts: Blades, vanes, rotor discs.
- Pump and valve components: Impellers, valve bodies, seals.
- Heat exchanger parts: Tubes, fins, headers.
- Solar panel components: Mounting brackets, frames, junction boxes.
- Electrical connectors: Cable connectors, terminal blocks, sockets.

5. Medical

- Surgical instruments: Forceps, scalpels, retractors.
- Implantable device components: Joint implants, pacemaker components.
- Prosthetic parts: Limb sockets, joint components.
- Medical equipment housings: Casing for diagnostic equipment, monitors.
- Dental appliance components: Denture frames, orthodontic brackets.

6. Oil and Gas

- Drilling tool components: Drill bits, drill collars, stabilizers.
- Valve bodies and seats: Gate valves, ball valves, control valves.
- Pump parts: Impellers, casings, seals.
- Subsea connectors: Couplings, connectors, riser systems.
- Pipeline fittings and flanges: Flange connections, pipe connectors, pipeline supports.

Aerospace and defence

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Gaskets and Seals
When Prototypes Fail in Production – and How to Prevent It Interior Components
When Prototypes Fail in Production – and How to Prevent It Shock Absorbers
When Prototypes Fail in Production – and How to Prevent It Engine Components
When Prototypes Fail in Production – and How to Prevent It Drones and UAVs

Engine Seal, Cargo Door Seal, Hydraulic System Seal, Landing Gear Door Seal and Fuselage Joint Seal

Armrest, Tray Table, Seat Cushion, Overhead Console, Window Frame, Headrest and Lavatory Fixture

Helicopter Skid Shock Absorber, Cockpit Seat Shock Absorber, Cargo Ramp Shock Absorber, Parachute Landing Shock Absorber, Nose Wheel Strut and Main Landing Gear Strut

Turbine Blade, Combustion Chamber Liner, Thrust Reverser Component, Fuel Nozzle, Engine Mount Isolator, Exhaust Duct Liner, Intake Manifold Gasket, Heat Shield, Engine Baffle Seal and Ignition Coil Boot

Drone Frame, Landing Gear Leg, Propeller Guard, Camera Mount, GPS Antenna Enclosure, Gimbal Stabilizer, Motor Mount Bracket and Arm Reinforcement Plate

Automotive

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Suspension Bushings
When Prototypes Fail in Production – and How to Prevent It Bump Stops
When Prototypes Fail in Production – and How to Prevent It Interior Trim
When Prototypes Fail in Production – and How to Prevent It Body Kits
When Prototypes Fail in Production – and How to Prevent It Tire Treads

Front Lower Control Arm Bushing, Rear Upper Control Arm Bushing, Sway Bar Bushing, Subframe Bushing, Strut Mount Bushing, Leaf Spring Bushing, Tie Rod End Bushing, Trailing Arm Bushing, Stabilizer Bar Bushing and Steering Rack Bushing

Front Bump Stop, Rear Bump Stop, Strut Bump Stop, Coil Spring Bump Stop, Shock Absorber Bump Stop, Sway Bar Bump Stop and Axle Bump Stop

Dashboard Panel Trim, Door Panel Insert, Cup Holder Trim, Headliner Trim, Seat Back Panel and Glove Compartment Trim

Front Bumper Spoiler, Rear Bumper Diffuser, Side Skirts, Fender Flares, Hood Scoop, Roof Spoiler and Front Lip Spoiler

Forklift Front Tire Tread, Forklift Rear Tire Tread, Industrial Vehicle Rear Tire Tread, Warehouse Equipment Tire Tread, Lawn Tractor Tire Tread and Material Handling Equipment Tire Tread

Consumer Products

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Footwear
When Prototypes Fail in Production – and How to Prevent It Toys and Games
When Prototypes Fail in Production – and How to Prevent It Appliance Handles
When Prototypes Fail in Production – and How to Prevent It Sporting Goods
When Prototypes Fail in Production – and How to Prevent It Personalized Promotional Items

Shoe Insoles, Shoe Outsoles, Shoe Midsoles, Heel Cushions, Arch Support Inserts and Shoelaces

Action figure parts, Puzzle pieces, Board game components, Toy car bodies and Doll accessories

Refrigerator Door Handle, Dishwasher Door Handle, Toaster Handle and Kitchen Appliance Drawer Handle

Tennis Racket Grip, Golf Club Grips, Bicycle Handlebar Grips, Fishing Rod Handles, Ski Pole Grips, Bowling Ball Finger Inserts and Ping Pong Paddle Grips

Branded keychains, Customized USB drives, Logo-bearing pens, Promotional event giveaways, Custom phone stands, Business card holders, Unique promotional trophies, Customized badges and buttons, Drink coasters with logos and Event-specific 3D printed gifts

Energy

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Oil Seals
When Prototypes Fail in Production – and How to Prevent It Hydroelectric Turbine Components
When Prototypes Fail in Production – and How to Prevent It Solar Panel Encapsulants
When Prototypes Fail in Production – and How to Prevent It Wind Turbine Components
When Prototypes Fail in Production – and How to Prevent It Battery Enclosures

Pump Shaft Seal, Compressor Piston Seal, Valve Stem Seal, Crankshaft Seal, Transmission Input Shaft Seal, Hydraulic Cylinder Seal, Gearbox Output Seal, Oil Cooler Seal, Gas Turbine Seal and Wellhead Seal

Turbine Blade, Runner Hub, Wicket Gate, Generator Stator, Penstock Liner, Draft Tube, Turbine Bearing, Blade Pitch Control Arm, Guide Vane and Turbine Nozzle

Solar Cell Encapsulation Sheet, Frame Gasket and Busbar Encapsulation

Wind Turbine Blade, Pitch Bearing Seal, Mainshaft Bearing, Rotor Hub, Gearbox Breather Plug and Tower Flange Gasket

Battery Terminal Cover, Ventilation Grommet, Battery Rack Enclosure, Cable Entry Grommet, Busbar Insulator and Battery Module Housing

Medical

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Medical Device Grips
When Prototypes Fail in Production – and How to Prevent It Prosthetic Limbs
When Prototypes Fail in Production – and How to Prevent It Medical Equipment Housings
When Prototypes Fail in Production – and How to Prevent It Orthopedic Braces
When Prototypes Fail in Production – and How to Prevent It Dental Models

Surgical Scissor Handle, Endoscope Control Knob, Blood Pressure Cuff Bulb, Ultrasound Probe Handle, Electrode Holder Grip and Insulin Pen Handle

Prosthetic Foot Sole, Shin Tube, Ankle Component, Suspension Sleeve and Cosmetic Cover

Anesthesia Machine Enclosure, Medical Cart Housing, Blood Analyzer Casing, MRI Machine Enclosure and Ventilator Housing

Elbow Brace Pad, Patella Stabilizer Brace and Lumbar Support Brace

Tooth Model Crown, Gingiva Model, Dental Bridge Model, Implant Model, Orthodontic Appliance Model, Bite Registration Model, Study Cast and Wax Bite Rim Model

Oil and Gas

CNC Parts

When Prototypes Fail in Production – and How to Prevent It Valve Seals
When Prototypes Fail in Production – and How to Prevent It Pipe Linings
When Prototypes Fail in Production – and How to Prevent It Offshore Equipment Components
When Prototypes Fail in Production – and How to Prevent It Pump Components
When Prototypes Fail in Production – and How to Prevent It Subsea Connectors

Gate Valve Seal, Ball Valve Seat, Butterfly Valve Seal, Plug Valve Seal, Check Valve Seal, Pressure Relief Valve Seal, Globe Valve Seal, Choke Valve Seat, Diaphragm Valve Seal and Control Valve Plug Seal

Pipeline Lining Sleeve, Pipe Bend Lining, Pipe Elbow Lining, Pipe Reducer Lining, Pipe Tee Lining, Pipe Flange Lining, Pipe Coupling Lining, Pipe Cross Lining, Pipe Transition Lining aaand Pipe Spool Lining

Offshore Platform Leg Pad, Subsea Umbilical Clamp, ROV (Remotely Operated Vehicle) Component, Offshore Crane Bushing, Subsea Cable Connector Seal, Offshore Buoyancy Module, Underwater Pipelaying Equipment Part, Offshore Anchor Block, Platform Mooring Component and Offshore Pipeline Pigging Component

Pump Impeller, Pump Volute, Pump Shaft Sleeve, Pump Wear Ring, Pump Casing, Pump Diffuser, Pump Coupling, Pump Suction Bell and Pump Discharge Nozzle

Subsea Electrical Connector, Subsea Hydraulic Connector, Subsea Fiber Optic Connector, Subsea Instrumentation Connector, Subsea Pressure Sensor Connector, Subsea Control System Connector, Subsea Wellhead Connector, Subsea Pipeline Connector, Subsea Manifold Connector and Subsea ROV Connector

The New Playbook for Material Agility: Designing Products That Survive Resin Shortages

March 3, 2026

A product manager at a medical device company got the call on a Tuesday morning. Their primary resin supplier declared force majeure. Production stopped.

When Prototypes Fail in Production - and How to Prevent It

February 24, 2026

A medical device startup spent eight months perfecting their prototypes. The design won awards. Investors lined up. Then they scaled to production, and the failure rate hit 40 percent.

How to Choose Between Manufacturing Processes for Functional Prototypes and Low-Volume Production

February 17, 2026

When selecting the manufacturing process for functional prototypes or low-volume production, the decision can often feel overwhelming.

Tooling as a Strategic Asset: The Missing Link in Manufacturing Continuity

February 10, 2026

The production line was ready. Materials were in. Demand was real. Then a single tool cracked.

How Design for Manufacturing and Assembly (DFMA) Builds Predictability from Day One

February 03, 2026

The first prototype looked perfect on screen. Clean geometry. Tight tolerances. Everyone nodded in the review.

Why Resilience Has Replaced Cost as the New Competitive Advantage in Injection Molding

January 27, 2026

In early 2020, a mid-sized molding supplier in Eastern Europe found itself in an unforeseen crisis.

The Biggest Prototyping Bottlenecks Engineers Face Today – And How to Fix Them

January 20, 2026

In Silicon Valley, a product team racing against time had their prototype ready but something was wrong.

Top 10 (CAD) Computer Aided Design Mistakes That Delay Manufacturing

January 13, 2026

The part looked right on the screen. It cleared internal review. It even passed a quick Design For Manufacturing (DFM) check inside the Computer Aided Design environment.

What’s Driving the Surge in Prototype Demand for Robotics, Aerospace, and Medical Industries

January 8, 2026

Rapid Prototyping Is No Longer a Safety Net. It’s the Critical Path.

Empowering Medical Innovations: PrintForm's Cutting-Edge Manufacturing Services

March 16, 2024

In the rapidly evolving healthcare and medical product development marketplace...

The Transformative Power of CNC Machining

October 17, 2023

In the realm of modern manufacturing, CNC machining redefines precision...

FDM 3D Printing Revolutionizing EV Manufacturing

July 07, 2023

The EV industry is evolving rapidly with the help of 3D printing...

3D PRINTING VS COVID-19

January 22, 2021

Dramatic healthcare needs during COVID-19 created urgent manufacturing demand...

PrintForm’s Online Instant Quoting System

October 27, 2020

Getting quotes has never been more convenient...

PrintForm Ends 2018 With NPS of 76

January 14, 2019

Another successful year for PrintForm driven by customer satisfaction...

Injection Molding Glossary

June 25, 2018

Our molding experience has grown tremendously over the years...

Design Considerations For SLS

August 25, 2017

SLS technology is suitable for complex designs and applications...

Unmatched Manufacturing Results through Precision Engineering

Experience the power of PrintForm’s CNC machining services, where precision meets versatility. Our advanced manufacturing processes and skilled engineering team offer an extensive array of finish and secondary processing options. With a commitment to exceeding your expectations, we prioritize your unique requirements over any specific technology or machine. Whether it’s high-quality plastic or metal components, our CNC machining capabilities deliver unmatched dimensional accuracy, critical surface finishes, and material-specific properties. Trust PrintForm to provide precision engineering solutions that empower your success in today’s competitive landscape.

1. Aerospace and Defense

CNC Materials

Stainless steel: A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.
Ren: A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.
POM (Acetol): A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.
Polycarbonate: An impact-resistant and transparent material often CNC machined into parts like safety goggles, electronic enclosures, and automotive lighting covers due to its excellent strength and optical clarity.
PMMA (Acrylic): A lightweight and transparent material commonly CNC machined into parts like display panels, signage, and lenses due to its optical clarity, UV resistance, and ease of machining.
Nylon: A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.
Aluminum: A lightweight and versatile material widely used for CNC machining parts such as housings, brackets, and heat sinks due to its high strength-to-weight ratio, excellent thermal conductivity, and corrosion resistance.
ABS: A durable and impact-resistant thermoplastic commonly CNC machined into parts like prototypes, enclosures, and consumer goods due to its good mechanical properties, ease of machining, and wide range of available colors.
Brass: A metal alloy known for its excellent machinability and corrosion resistance, often CNC machined into parts like fittings, valves, and decorative components due to its aesthetic appeal and durability.
Copper: A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.
Mild steel: A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.
Magnesium: A lightweight metal used for CNC machining parts like aerospace components, electronic housings, and automotive parts due to its high strength-to-weight ratio, excellent machinability, and good thermal conductivity.
Foam: A lightweight and versatile material used for CNC machining applications like packaging inserts, architectural models, and signage due to its ease of machining, low density, and impact-absorbing properties.
Delrin: A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.

CNC Finishes

Anodizing: An electrochemical process that enhances the surface of metal parts with a protective oxide layer, offering increased corrosion resistance and improved aesthetics. It is preferred for aluminum parts that require durability, color options, and resistance to wear and weathering.
Painting: The application of a protective coating on CNC machined parts to provide aesthetic appeal, color customization, and added protection against corrosion. It is preferred when parts require specific colors, branding, or a decorative finish.
Pad Printing: A printing technique where ink is transferred from a silicone pad onto CNC machined parts, allowing for detailed and precise graphics, text, or logos to be applied. It is preferred when parts require intricate designs, branding, or labeling.
Sanding and Polishing: The process of smoothing the surface of CNC machined parts through abrasion to achieve a desired finish. It is preferred when parts require a smooth, glossy, or reflective surface for aesthetics, improved functionality, or ease of cleaning.
Vapor Polishing: A process that involves exposing CNC machined parts to vaporized solvents, resulting in the surface being melted and re-solidified, producing a high-gloss finish. It is preferred for transparent or clear parts, such as acrylic or polycarbonate, when a glossy and optically clear finish is desired.
Blasting: The use of abrasive materials, such as sand or glass beads, to remove surface imperfections, burrs, or scale from CNC machined parts, resulting in a uniform texture or a matte finish. It is preferred when parts require a textured appearance, improved adhesion for coatings, or to remove sharp edges or burrs.

CNC Parts

1. Stainless steel

A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.

2. Ren

A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.

3. POM (Acetol)

A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.

4. Polycarbonate

5. PMMA (Acrylic)

A lightweight and transparent material commonly CNC machined into parts like display panels, signage, and lenses due to its optical clarity, UV resistance, and ease of machining.

6. Nylon

A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.

7.Aluminum

8. ABS

9.Brass

10. Copper

A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.

11. Mild Steel

A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.

12. Magnesium

13. Foam

14. Delrin

A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.

1. Stainless steel

A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.

2. Ren

A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.

3. POM (Acetol)

A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.

4. Polycarbonate

5. PMMA (Acrylic)

A lightweight and transparent material commonly CNC machined into parts like display panels, signage, and lenses due to its optical clarity, UV resistance, and ease of machining.

6. Nylon

A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.

7.Aluminum

8. ABS

9.Brass

10. Copper

A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.

11. Mild Steel

A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.

12. Magnesium

13. Foam

14. Delrin

A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.

Material	Mechanical Properties	Physical Properties	Chemical Properties	Features	Common Applications
High Temp PC Like	Tensile Strength: 60-70 MPa Impact Strength: 10-20 kJ/m² Heat Deflection Temperature: 135-150°C	Transparent or translucent Good dimensional stability	Resistant to many chemicals and oils	Excellent transparency High temperature resistance	Aerospace and Defense: Transparent canopies, Medical: Medical device components
High Temp ABS Like	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Heat Deflection Temperature: 100-120°C	Various colors available Good dimensional stability	Resistant to many chemicals and oils	Suitable for high-temperature applications	Aerospace and Defense: Engine components, Automotive: Engine components
High Strength ABS Like	Tensile Strength: 60-80 MPa Impact Strength: 20-40 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	Various colors available Low density Good dimensional stability	Resistant to many chemicals and oils	High strength and impact resistance Lightweight	Automotive: Bumpers, Aerospace and Defense: Structural components
ABS Like Gray	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	Gray color Low density Good dimensional stability	Resistant to many chemicals and oils	Gray appearance Lightweight Durable	Automotive: Interior components, consumer products: casings, fittings
ABS Like Black	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	Black color Low density Good dimensional stability	Resistant to many chemicals and oils	Black appearance Lightweight - Durable	Consumer Products: Electronics casings, automotive interior parts
ABS Like White	Tensile Strength: 40-60 MPa Impact Strength: 5-20 kJ/m² Density: 1.03 g/cm³ Melting Point: 220-260°C	White color Low density Good dimensional stability	Resistant to many chemicals and oils	White appearance Lightweight Durable	Consumer Products: Electronics casings, toys, kitchen appliances
ABS	Good impact resistance	Density: 1.03 g/cm³	Resistant to diluted acids, alkalis	High strength, versatility, cost-effective	Automotive, Consumer Products
ABS – M30i	- Good tensile strength	- Density: 1.04 g/cm³	- Medical grade	- Biocompatible, sterilizable, suitable for medical devices	Medical
ABS ESD	- Static-dissipative properties	- Density: 1.06 g/cm³	- ESD protection	- Prevents electrostatic discharge, suitable for electronics	Aerospace and Defense, Consumer Products
ABS-Like	- High toughness and durability	- Density: Varies by formulation	- Resistant to various chemicals	- Resembles ABS but may offer specific improvements	Varies by formulation
Accura 25	- High accuracy and resolution	- Density: Varies by formulation	- Photopolymer	- Used in stereolithography 3D printing, fine details	Consumer Products, Medical, Aerospace and Defense
Accura 60	- High strength and durability	- Density: Varies by formulation	- Photopolymer	- Tough and durable, suitable for functional prototypes	Consumer Products, Aerospace and Defense
Accura AMX Rigid Black	- High impact resistance	- Density: Varies by formulation	- Photopolymer	- Rigid and durable, good for functional prototypes	Consumer Products, Aerospace and Defense
Accura ClearVue	- High transparency and clarity	- Density: Varies by formulation	- Photopolymer	- Crystal clear appearance, ideal for clear parts	Consumer Products, Medical
Accura Xtreme Grey/White	- High toughness and durability	- Density: Varies by formulation	- Photopolymer	- Resistant to high temperatures, strong and rigid	Consumer Products, Aerospace and Defense
ASA	- Excellent UV resistance	- Density: 1.07 g/cm³	- Weather-resistant	- Outdoor durability, retains color and strength in sunlight	Automotive, Consumer Products
Nylon	- High tensile strength	- Density: 1.15 g/cm³	- Resistant to moisture, chemicals	- Tough and durable, suitable for functional parts	Aerospace and Defense, Automotive, Consumer Products
Nylon 11 Flame Retardant	- Flame retardant properties	- Density: Varies by formulation	- Flame-resistant	- Fire safety, suitable for applications requiring flame resistance	Aerospace and Defense, Automotive
Nylon 12	- Good chemical resistance	- Density: 1.02 g/cm³	- Resistant to oils, greases	- Versatile, suitable for various industrial applications	Aerospace and Defense, Automotive, Consumer Products, Oil and Gas
Nylon 6	- High impact strength	- Density: 1.14 g/cm³	- Resistant to moisture, abrasion	- Durable, excellent for applications requiring impact resistance	Automotive, Consumer Products
PA 12 Glass Beads	- Improved stiffness and dimensional stability	- Density: Varies by formulation	- Reinforced with glass beads	- Increased stiffness, suitable for engineering applications	Automotive, Aerospace and Defense
PC-ISO	- High strength and heat resistance	- Density: Varies by formulation	- Biocompatible	- Suitable for medical and aerospace applications	Aerospace and Defense, Medical
PC+ABS	- Good impact resistance	- Density: Varies by formulation	- Resistant to chemicals	- Blends properties of PC and ABS, versatile material	Automotive, Consumer Products
PETG	- Excellent transparency and impact resistance	- Density: 1.27 g/cm³	- Food-safe, BPA-free	- Clarity and toughness, ideal for packaging and displays	Consumer Products, Medical
PLA	- Biodegradable and easy to print	- Density: 1.24 g/cm³	- Biodegradable	- Eco-friendly, easy to 3D print	Consumer Products, Medical
Polycarbonate (PC)	- High impact resistance, optical clarity	- Density: 1.20 g/cm³	- Excellent optical properties	- Exceptional clarity and strength, suitable for transparent parts	Aerospace and Defense, Consumer Products, Medical
Polypropylene	- Low density and good chemical resistance	- Density: 0.90 g/cm³	- Resistant to moisture, chemicals	- Lightweight, suitable for low-stress applications	Consumer Products, Automotive
Rubber-Like	- Flexible and rubber-like properties	- Density: Varies by formulation	- Flexible elastomer	- Mimics rubber, suitable for gaskets and seals	Automotive, Consumer Products
Somos Evolve	- High strength and heat resistance	- Density: Varies by formulation	- Photopolymer	- Engineering-grade material, suitable for functional prototypes	Aerospace and Defense, Automotive
Somos PerFORM	- High stiffness and heat resistance	- Density: Varies by formulation	- Photopolymer	- Strong and stiff, ideal for high-temperature applications	Aerospace and Defense
Somos Waterclear	- High transparency and clarity	- Density: Varies by formulation	- Photopolymer	- Transparent, suitable for clear prototypes and parts	Consumer Products, Medical
Somos Watershed	- Excellent clarity and water resistance	- Density: Varies by formulation	- Photopolymer	- Waterproof, suitable for water-resistant parts	Consumer Products, Medical
ST-130	- High toughness and durability	- Density: Varies by formulation	- Photopolymer	- Rigid, tough, and durable, good for functional prototypes	Consumer Products, Aerospace and Defense
TPU 88A	- Flexible and elastomeric properties	- Density: Varies by formulation	- Thermoplastic polyurethane	- Flexibility and resilience, suitable for elastomeric parts	Automotive, Consumer Products, Medical
Ultem 1010	- High strength, heat, and chemical resistance	- Density: 1.27 g/cm³	- Flame-resistant, UL 94 V0	- Engineering-grade thermoplastic with excellent properties	Aerospace and Defense, Automotive, Oil and Gas
Ultem 9085	- High strength, heat, and chemical resistance	- Density: 1.27 g/cm³	- Flame-resistant, UL 94 V0	- Suitable for aerospace and transportation applications	Aerospace and Defense, Automotive
Vero	- Rigid and durable	- Density: Varies by formulation	- Photopolymer	- Versatile material, good for prototypes and models	Consumer Products, Aerospace and Defense
VeroClear	- High transparency and clarity	- Density: Varies by formulation	- Photopolymer	- Transparent appearance, ideal for clear parts	Consumer Products, Medical

CNC Materials

Stainless steel: A strong and corrosion-resistant material commonly used for CNC machining parts like precision components, medical instruments, and automotive components.
Ren: A durable thermoplastic material suitable for CNC machining complex parts like gears, bearings, and bushings, known for its excellent dimensional stability and low friction properties.
POM (Acetol): A versatile engineering plastic widely used for CNC machining components such as precision gears, rollers, and valve bodies due to its low friction, high strength, and dimensional stability.
Polycarbonate: An impact-resistant and transparent material often CNC machined into parts like safety goggles, electronic enclosures, and automotive lighting covers due to its excellent strength and optical clarity.
PMMA (Acrylic): A lightweight and transparent material commonly CNC machined into parts like display panels, signage, and lenses due to its optical clarity, UV resistance, and ease of machining.
Nylon: A strong and flexible material used for CNC machining parts like gears, pulleys, and bearings due to its high wear resistance, low friction, and excellent mechanical properties.
Aluminum: A lightweight and versatile material widely used for CNC machining parts such as housings, brackets, and heat sinks due to its high strength-to-weight ratio, excellent thermal conductivity, and corrosion resistance.
ABS: A durable and impact-resistant thermoplastic commonly CNC machined into parts like prototypes, enclosures, and consumer goods due to its good mechanical properties, ease of machining, and wide range of available colors.
Brass: A metal alloy known for its excellent machinability and corrosion resistance, often CNC machined into parts like fittings, valves, and decorative components due to its aesthetic appeal and durability.
Copper: A highly conductive and malleable material often CNC machined into electrical connectors, heat sinks, and RF shields due to its excellent electrical and thermal properties.
Mild steel: A low-carbon steel commonly CNC machined into parts like brackets, shafts, and structural components due to its strength, machinability, and cost-effectiveness.
Magnesium: A lightweight metal used for CNC machining parts like aerospace components, electronic housings, and automotive parts due to its high strength-to-weight ratio, excellent machinability, and good thermal conductivity.
Foam: A lightweight and versatile material used for CNC machining applications like packaging inserts, architectural models, and signage due to its ease of machining, low density, and impact-absorbing properties.
Delrin: A high-performance engineering plastic known for its excellent dimensional stability, low friction, and high wear resistance, often CNC machined into parts like bushings, gears, and bearings.

CNC Finishes

Anodizing: An electrochemical process that enhances the surface of metal parts with a protective oxide layer, offering increased corrosion resistance and improved aesthetics. It is preferred for aluminum parts that require durability, color options, and resistance to wear and weathering.
Painting: The application of a protective coating on CNC machined parts to provide aesthetic appeal, color customization, and added protection against corrosion. It is preferred when parts require specific colors, branding, or a decorative finish.
Pad Printing: A printing technique where ink is transferred from a silicone pad onto CNC machined parts, allowing for detailed and precise graphics, text, or logos to be applied. It is preferred when parts require intricate designs, branding, or labeling.
Sanding and Polishing: The process of smoothing the surface of CNC machined parts through abrasion to achieve a desired finish. It is preferred when parts require a smooth, glossy, or reflective surface for aesthetics, improved functionality, or ease of cleaning.
Vapor Polishing: A process that involves exposing CNC machined parts to vaporized solvents, resulting in the surface being melted and re-solidified, producing a high-gloss finish. It is preferred for transparent or clear parts, such as acrylic or polycarbonate, when a glossy and optically clear finish is desired.
Blasting: The use of abrasive materials, such as sand or glass beads, to remove surface imperfections, burrs, or scale from CNC machined parts, resulting in a uniform texture or a matte finish. It is preferred when parts require a textured appearance, improved adhesion for coatings, or to remove sharp edges or burrs.

CNC Parts

Aerospace and Defense:
1. Aircraft components: Wings, fuselage, landing gear.
2. Engine parts: Turbine blades, combustion chambers, fuel nozzles.
3. Aerospace fasteners: Turbine blades, combustion chambers, fuel nozzles.
4. Missile components: Turbine blades, combustion chambers, fuel nozzles.
5. Defense system parts: Turbine blades, combustion chambers, fuel nozzles.
Automotive:
1. Engine components: Cylinder heads, pistons, crankshafts.
2. Transmission parts: Gears, shafts, synchronizers.
3. Brackets and mounts: Engine mounts, suspension brackets.
4. Interior trim parts: Dashboard components, door panels.
5. Automotive lighting housings: Headlight assemblies, taillight covers.
Consumer Products:
1. Electronic enclosures: Housing for electronic devices, control panels.
2. Appliance components: Handles, knobs, control buttons.
3. Custom knobs and handles: Decorative or functional knobs and handles.
4. Decorative accessories: Ornaments, figurines, jewelry components.
5. Personal care product components: Cosmetic containers, toothbrush handles.
Energy:
1. Turbine parts: Blades, vanes, rotor discs.
2. Pump and valve components: Impellers, valve bodies, seals.
3. Heat exchanger parts: Tubes, fins, headers.
4. Solar panel components: Mounting brackets, frames, junction boxes.
5. Electrical connectors: Cable connectors, terminal blocks, sockets.
Medical:
1. Surgical instruments: Forceps, scalpels, retractors.
2. Implantable device components: Joint implants, pacemaker components.
3. Prosthetic parts: Limb sockets, joint components.
4. Medical equipment housings: Casing for diagnostic equipment, monitors.
5. Dental appliance components: Denture frames, orthodontic brackets.
Oil and Gas:
1. Drilling tool components: Drill bits, drill collars, stabilizers.
2. Valve bodies and seats: Gate valves, ball valves, control valves.
3. Pump parts: Impellers, casings, seals.
4. Subsea connectors: Couplings, connectors, riser systems.
5. Pipeline fittings and flanges: Flange connections, pipe connectors, pipeline supports.

“Our experience with PrintForm was very positive. The interaction with their engineering team was very enlightening and they were extremely helpful in assisting us with getting our item from concept to completed prototype.”

JONATHAN R., AEROSPACE DESIGN TECHNICIAN

Need more details?

We are here to assist. Contact us by phone, email or via our social media channels.

When Prototypes Fail in Production - and How to Prevent It

The Gap Between Prototype and Production

Where Prototypes Actually Fail

1. Material inconsistency kills scalability.

2. Tolerance stack-up compounds in assembly.

3. Environmental factors emerge under volume.

1. Aerospace and Defense

Turbine Blades

Bulkheads

Control Surfaces

Instrument panel bezels

Fuselage frames

Aircraft skins

Landing gear struts

Wing Ribs

Wing spars

2. Automotive

3. Consumer Products

4. Energy

5. Medical

6. Oil and Gas

Aerospace and defence

CNC Parts

Engine Seal, Cargo Door Seal, Hydraulic System Seal, Landing Gear Door Seal and Fuselage Joint Seal

Armrest, Tray Table, Seat Cushion, Overhead Console, Window Frame, Headrest and Lavatory Fixture

Helicopter Skid Shock Absorber, Cockpit Seat Shock Absorber, Cargo Ramp Shock Absorber, Parachute Landing Shock Absorber, Nose Wheel Strut and Main Landing Gear Strut

Turbine Blade, Combustion Chamber Liner, Thrust Reverser Component, Fuel Nozzle, Engine Mount Isolator, Exhaust Duct Liner, Intake Manifold Gasket, Heat Shield, Engine Baffle Seal and Ignition Coil Boot

Drone Frame, Landing Gear Leg, Propeller Guard, Camera Mount, GPS Antenna Enclosure, Gimbal Stabilizer, Motor Mount Bracket and Arm Reinforcement Plate

Automotive

CNC Parts

Front Lower Control Arm Bushing, Rear Upper Control Arm Bushing, Sway Bar Bushing, Subframe Bushing, Strut Mount Bushing, Leaf Spring Bushing, Tie Rod End Bushing, Trailing Arm Bushing, Stabilizer Bar Bushing and Steering Rack Bushing

Front Bump Stop, Rear Bump Stop, Strut Bump Stop, Coil Spring Bump Stop, Shock Absorber Bump Stop, Sway Bar Bump Stop and Axle Bump Stop

Dashboard Panel Trim, Door Panel Insert, Cup Holder Trim, Headliner Trim, Seat Back Panel and Glove Compartment Trim

Front Bumper Spoiler, Rear Bumper Diffuser, Side Skirts, Fender Flares, Hood Scoop, Roof Spoiler and Front Lip Spoiler

Forklift Front Tire Tread, Forklift Rear Tire Tread, Industrial Vehicle Rear Tire Tread, Warehouse Equipment Tire Tread, Lawn Tractor Tire Tread and Material Handling Equipment Tire Tread

Design for Manufacturing from the Start

Validation That Matters

Making the Transition

Partner with Manufacturing Experts Who Understand Both Worlds

Consumer Products

CNC Parts

Shoe Insoles, Shoe Outsoles, Shoe Midsoles, Heel Cushions, Arch Support Inserts and Shoelaces

Action figure parts, Puzzle pieces, Board game components, Toy car bodies and Doll accessories

Refrigerator Door Handle, Dishwasher Door Handle, Toaster Handle and Kitchen Appliance Drawer Handle

Tennis Racket Grip, Golf Club Grips, Bicycle Handlebar Grips, Fishing Rod Handles, Ski Pole Grips, Bowling Ball Finger Inserts and Ping Pong Paddle Grips

Branded keychains, Customized USB drives, Logo-bearing pens, Promotional event giveaways, Custom phone stands, Business card holders, Unique promotional trophies, Customized badges and buttons, Drink coasters with logos and Event-specific 3D printed gifts

Energy

CNC Parts

Pump Shaft Seal, Compressor Piston Seal, Valve Stem Seal, Crankshaft Seal, Transmission Input Shaft Seal, Hydraulic Cylinder Seal, Gearbox Output Seal, Oil Cooler Seal, Gas Turbine Seal and Wellhead Seal

Turbine Blade, Runner Hub, Wicket Gate, Generator Stator, Penstock Liner, Draft Tube, Turbine Bearing, Blade Pitch Control Arm, Guide Vane and Turbine Nozzle

Solar Cell Encapsulation Sheet, Frame Gasket and Busbar Encapsulation

Wind Turbine Blade, Pitch Bearing Seal, Mainshaft Bearing, Rotor Hub, Gearbox Breather Plug and Tower Flange Gasket

Battery Terminal Cover, Ventilation Grommet, Battery Rack Enclosure, Cable Entry Grommet, Busbar Insulator and Battery Module Housing

Medical

CNC Parts

Surgical Scissor Handle, Endoscope Control Knob, Blood Pressure Cuff Bulb, Ultrasound Probe Handle, Electrode Holder Grip and Insulin Pen Handle

Prosthetic Foot Sole, Shin Tube, Ankle Component, Suspension Sleeve and Cosmetic Cover

Anesthesia Machine Enclosure, Medical Cart Housing, Blood Analyzer Casing, MRI Machine Enclosure and Ventilator Housing

Elbow Brace Pad, Patella Stabilizer Brace and Lumbar Support Brace

Tooth Model Crown, Gingiva Model, Dental Bridge Model, Implant Model, Orthodontic Appliance Model, Bite Registration Model, Study Cast and Wax Bite Rim Model

Oil and Gas

CNC Parts

Gate Valve Seal, Ball Valve Seat, Butterfly Valve Seal, Plug Valve Seal, Check Valve Seal, Pressure Relief Valve Seal, Globe Valve Seal, Choke Valve Seat, Diaphragm Valve Seal and Control Valve Plug Seal

Pipeline Lining Sleeve, Pipe Bend Lining, Pipe Elbow Lining, Pipe Reducer Lining, Pipe Tee Lining, Pipe Flange Lining, Pipe Coupling Lining, Pipe Cross Lining, Pipe Transition Lining aaand Pipe Spool Lining

Pump Impeller, Pump Volute, Pump Shaft Sleeve, Pump Wear Ring, Pump Casing, Pump Diffuser, Pump Coupling, Pump Suction Bell and Pump Discharge Nozzle

Subsea Electrical Connector, Subsea Hydraulic Connector, Subsea Fiber Optic Connector, Subsea Instrumentation Connector, Subsea Pressure Sensor Connector, Subsea Control System Connector, Subsea Wellhead Connector, Subsea Pipeline Connector, Subsea Manifold Connector and Subsea ROV Connector

1. Aerospace and Defense

Turbine Blades

Bulkheads

Control Surfaces

Instrument panel bezels

Fuselage frames

Aircraft skins

Landing gear struts

Wing Ribs

Wing spars

2. Automotive

3. Consumer Products

4. Energy

5. Medical

When Prototypes Fail in Production
- and How to Prevent It
